Replacement Parts for Mitsubishi Brake Drum
Select your vehicle for the best product fit
  • Select Vehicle by Model
  • Select Vehicle by VIN
Select Make
Select Model
Select Year
or

Mitsubishi Brake Drum

< Back to View All
Brake Drums & Brake Shoes
  • Department
  • Series
  • Brands
  • Prices

15 Products found

Show Item:
  • 30
  • 60
  • 90
Sort by:
Recommended
Filter
Sort
View by
  • Centric Premium Rear Brake Drum for Mitsubishi - 122.46026

    Centric® Premium Rear Brake Drum for Mitsubishi

    PartNumber: 122.46026
    Product Specifications
    • UPC: 805890978473
    • Part Description: Mitsubishi Premium Rear Brake Drum
    $128.94
  • DuraGo Rear Brake Drum for Mitsubishi - BD920118

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD920118
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 139.7mm (5.5")
    • Bolt Hole Diameter: 17.2mm (0.68")
    • Bolt Hole Quantity: 5
    • Brake Surface Width: 73.5mm (2.89")
    • Center Hole Diameter: 78.4mm (3.09")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 111.8mm (4.40")
    • Maximum Diameter: 297.5mm (11.71")
    • Nominal Diameter: 295mm (11.61")
    • Outside Diameter: 358.7mm (14.12")
    • Type: Plain Cooling Fins
    • UPC: 756632161250
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
    $59.06
  • Centric Premium Rear Brake Drum for Mitsubishi - 122.67044

    Centric® Premium Rear Brake Drum for Mitsubishi

    PartNumber: 122.67044
    Product Specifications
    • UPC: 805890040590
    • Part Description: Mitsubishi Premium Rear Brake Drum
    $94.26
  • DuraGo Rear Brake Drum for Mitsubishi - BD35080

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD35080
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 139.7mm (5.5")
    • Bolt Hole Diameter: 12.2mm (0.48")
    • Bolt Hole Quantity: 6
    • Brake Surface Width: 75.7mm (2.98")
    • Center Hole Diameter: 108mm (4.25")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 93mm (3.66")
    • Maximum Diameter: 272mm (10.71")
    • Nominal Diameter: 270mm (10.63")
    • Outside Diameter: 330.5mm (13.01")
    • Type: Plain Cooling Fins
    • UPC: 756632117844
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
    $39.71
  • Centric Premium Rear Brake Drum for Mitsubishi - 122.46018

    Centric® Premium Rear Brake Drum for Mitsubishi

    PartNumber: 122.46018
    Product Specifications
    • UPC: 805890037385
    • Part Description: Mitsubishi Premium Rear Brake Drum
    $29.02
  • DuraGo Rear Brake Drum for Mitsubishi - BD35101

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD35101
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 114.3mm (4.5")
    • Bolt Hole Diameter: 12.8mm (0.50")
    • Bolt Hole Quantity: 5
    • Brake Surface Width: 38.6mm (1.52")
    • Center Hole Diameter: 90mm (3.54")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 60mm (2.36")
    • Maximum Diameter: 230.6mm (9.08")
    • Nominal Diameter: 228.6mm (9")
    • Outside Diameter: 279mm (10.98")
    • Type: Plain Cooling Fins
    • UPC: 756632153033
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
    $23.56
  • DuraGo Rear Brake Drum for Mitsubishi - BD35016

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD35016
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 114.3mm (4.5")
    • Bolt Hole Diameter: 12.7mm (0.5")
    • Bolt Hole Quantity: 5
    • Brake Surface Width: 49.4mm (1.94")
    • Center Hole Diameter: 90mm (3.54")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 62.2mm (2.45")
    • Maximum Diameter: 230mm (9.06")
    • Nominal Diameter: 228.5mm (9")
    • Outside Diameter: 266.3mm (10.48")
    • Type: Plain Cooling Fins
    • UPC: 756632117349
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
    $22.08
  • DuraGo Rear Brake Drum for Mitsubishi - BD35085

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD35085
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 114.3mm (4.5")
    • Bolt Hole Diameter: 12.8mm (0.50")
    • Bolt Hole Quantity: 4
    • Brake Surface Width: 42mm (1.65")
    • Center Hole Diameter: 90.1mm (3.55")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 60mm (2.36")
    • Maximum Diameter: 205mm (8.07")
    • Nominal Diameter: 202.95mm (7.99")
    • Outside Diameter: 243mm (9.57")
    • Type: Plain Cooling Fins
    • UPC: 756632132021
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
    $20.03
  • DuraGo Rear Brake Drum for Mitsubishi - BD920134

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD920134
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 114.3mm (4.5")
    • Bolt Hole Diameter: 12.5mm (0.49")
    • Bolt Hole Quantity: 5
    • Brake Surface Width: 40.3mm (1.59")
    • Center Hole Diameter: 80mm (3.15")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 59.3mm (2.33")
    • Maximum Diameter: 205mm (8.07")
    • Nominal Diameter: 203mm (7.99")
    • Outside Diameter: 240mm (9.45")
    • Type: Plain Cooling Fins
    • UPC: 756632172737
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
    $19.77
  • Centric Premium Rear Brake Drum for Mitsubishi - 122.46027

    Centric® Premium Rear Brake Drum for Mitsubishi

    PartNumber: 122.46027
    Product Specifications
    • UPC: 889590379174
    • Part Description: Mitsubishi Premium Rear Brake Drum
    $109.56
  • DuraGo Rear Brake Drum for Mitsubishi - BD3544

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD3544
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 139.7mm (5.5")
    • Bolt Hole Diameter: 12.5mm (0.49")
    • Bolt Hole Quantity: 6
    • Brake Surface Width: 57.7mm (2.27")
    • Center Hole Diameter: 93.5mm (3.68")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 83.3mm (3.28")
    • Maximum Diameter: 256mm (10.08")
    • Nominal Diameter: 254mm (10")
    • Outside Diameter: 303mm (11.93")
    • Type: Plain Cooling Fins
    • UPC: 756632108996
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
  • DuraGo Rear Brake Drum for Mitsubishi - BD35002

    DuraGo® Rear Brake Drum for Mitsubishi

    PartNumber: BD35002
    Product Specifications
    • Abs Sensor Ring Includes: No
    • Bolt Circle Diameter: 100mm (3.94")
    • Bolt Hole Diameter: 13mm (0.51")
    • Bolt Hole Quantity: 4
    • Brake Surface Width: 43.5mm (1.71")
    • Center Hole Diameter: 64.05mm (2.52")
    • Construction: Full Cast
    • Drum Type: Floating
    • Height: 64.5mm (2.54")
    • Maximum Diameter: 205mm (8.07")
    • Nominal Diameter: 203mm (7.99")
    • Outside Diameter: 241mm (9.49")
    • Type: Plain Cooling Fins
    • UPC: 756632117325
    • Part Description: Mitsubishi Rear Brake Drum
    More Info
  • Centric Premium™ Brake Drum for Mitsubishi - 122.46001

    Centric® Premium™ Brake Drum for Mitsubishi

    PartNumber: 122.46001
    Product Specifications
    • UPC: 805890032533
    • Part Description: Mitsubishi Premium™ Brake Drum
  • Centric Premium Rear Brake Drum for Mitsubishi - 122.46004

    Centric® Premium Rear Brake Drum for Mitsubishi

    PartNumber: 122.46004
    Product Specifications
    • UPC: 805890037347
    • Part Description: Mitsubishi Premium Rear Brake Drum
  • Centric Premium™ Brake Drum for Mitsubishi - 122.46025

    Centric® Premium™ Brake Drum for Mitsubishi

    PartNumber: 122.46025
    Product Specifications
    • UPC: 805890978381
    • Part Description: Mitsubishi Premium™ Brake Drum

About Mitsubishi Brake Drum

Mitsubishi produces passenger and economy cars and commercial and sport utility vehicles. It grew with the Southeast Asian economy in the mid-1990s, controlling about 25% of the region's truck and automobile markets. Classic parts like the brake drum contribute to the success of Mitsubishi. The Mitsubishi brake drum rotates in sync with the wheel and axle. When the user presses on the brakes, the lining is pushed against the surface, causing friction to slow or stop the vehicle. The Mitsubishi brake drum parts are usually accompanied by two shoes that have a metal framing in which the friction lining is secured. When applying the Mitsubishi brake drum parts, the friction linings make contact with the surface of the Mitsubishi brake drum causing the springs to retract the shoes once the user is done pressing the brakes.
Mitsubishi provides a large selection of high-performance parts. But after a long time, the worn Mitsubishi brake drum might cause huge problems. The Mitsubishi brake drum is part of the drum brake system, which works in correlation with a brake shoe to decelerate the rotation of a wheel. The removal process for Mitsubishi brake drum parts is as follows. Remove the hubcap (if applicable). Next, remove the lug nuts and wheel from the vehicle. Then, remove the Mitsubishi brake drum retaining screws. Finally, pull the brake drum parts off gently to not damage any parts around. We provide considerate and nice services to consumers. There are lots of top-quality and durable parts available on our website.
