Product Specifications- Core Height: 18.9000"
- Core Thickness: 0.9800"
- Core Width: 25.5000"
- Inlet Diameter: 1.5000"
- Outlet Diameter: 1.5000"
- UPC: 042511225756
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Bottom Header: 1 7/8" x 27 7/16"
- Core Size: 16 3/4" x 26 11/16" x 5/8"
- Manufactured Material: Plastic/Aluminum
- OE Part Number: 5-86206-020-0
- Rows: 1
- Top Header: 1 5/16" x 27 7/16"
- UPC: 762405250243
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 9/16 Left
- Box Height (in): 5 4/16
- Box Length (in): 26 1/8
- Box Weight (lbs): 11
- Box Width (in): 26 1/8
- Core Length: 18 1/8
- Core Material: Aluminum
- Core Thickness: 7/8
- Core Width: 22 3/4
- Cross-flow/ Down-flow: Down Flow
- Hazardous Material: No
- Inlet Length (in): 23 1/4
- Inlet Width (in): 1 7/8
- No. Of Rows: 1
- OE Part Number: 15120862, 15199308, CU2707, 2707, 8012707
- Oil Cooler (in): 11 1/2 (high-efficiency Plate Type)
- Outlet Length(in): 23 1/4
- Outlet Width: 1 7/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core;with quick-connect oil cooler fittings;Manufactured with steel crimps to strengthen radiator by 40% over O.E.
- Top Hose Fitting (in): 1 5/16 Right
- UPC: 710353034712
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Core Height: 16.7500"
- Core Thickness: 1.0600"
- Core Width: 24.0000"
- Inlet Diameter: 1.5000"
- Outlet Diameter: 1.5000"
- UPC: 042511178533
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Core Material: Aluminum
- Height: 23 5/8"
- Inlet: 1 5/16"
- Inlet Header: 16 5/8" x 2 1/2"
- Outlet: 1 5/16"
- Outlet Header: 16 5/8" x 2 1/2"
- Row: 1
- Tank Material: Plastic
- Thickness: 1"
- TOC: Plated; 11 1/2"
- UPC: 671607729856
- Width: 15"
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 1/4 Right
- Box Height (in): 5 4/16
- Box Length (in): 29 7/16
- Box Weight (lbs): 12
- Box Width (in): 23 1/8
- Core Length: 16 3/4
- Core Material: Aluminum
- Core Thickness: 7/8
- Core Width: 26 11/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4514
- Hazardous Material: No
- Inlet Length (in): 27 1/4
- Inlet Width (in): 1 5/8
- No. Of Rows: 1
- OE Part Number: 5-86206-020-0, CU1815, 8011815, 19010-P1E-A51, 5-86202-357-0, 19010-PEA-901, 221-3203
- Oil Cooler (in): 12 13/16 (high-effeciency Concentric Type)
- Outlet Length(in): 27 1/4
- Outlet Width: 1 5/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 1/4 Centre
- UPC: 710353026038
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Core Height: 16.7500"
- Core Thickness: 0.6250"
- Core Width: 26.6870"
- Inlet Diameter: 1.2500"
- Outlet Diameter: 1.2500"
- UPC: 042511174979
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Core Material: Aluminum
- Height: 16 3/4"
- Inlet: 1 1/2"
- Inlet Header: 24 3/8" x 1 3/4"
- Outlet: 1 1/2"
- Outlet Header: 24 3/8" x 1 3/4"
- Row: 1
- Tank Material: Plastic
- Thickness: 1"
- TOC: Concentric; 1 1/8" Diameter; 14 3/4" Distance
- UPC: 671607710410
- Width: 24 5/16"
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Core Material: Aluminum
- Height: 18 1/16"
- Inlet: 1 5/16"
- Inlet Header: 23 15/16" x 2 5/16"
- Outlet: 1 9/16"
- Outlet Header: 23 15/16" x 2 5/16"
- Row: 1
- Tank Material: Plastic
- Thickness: 7/8"
- TOC: Plated; 11 1/2"
- UPC: 671607749533
- Width: 23 1/8"
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Core Material: Aluminum
- Height: 16 3/4"
- Inlet: 1 1/4"
- Inlet Header: 27 1/2" x 1 1/4"
- Outlet: 1 1/4"
- Outlet Header: 27 1/2" x 1 1/4"
- Row: 1
- Tank Material: Plastic
- Thickness: 5/8"
- TOC: Concentric; 1" Diameter; 12 7/8" Distance
- UPC: 671607708745
- Width: 26 11/16"
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Bottom Header: 2 1/16" x 25 1/16"
- Core Size: 16 3/4" x 24" x 1 1/16"
- Manufactured Material: Plastic/Aluminum
- OE Part Number: 8-52478-811-0
- Rows: 1
- Top Header: 2 1/16" x 25 1/16"
- UPC: 762405911953
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 5 1/2
- Box Length (in): 27 5/16
- Box Weight (lbs): 11
- Box Width (in): 23 9/16
- Core Length: 16 3/4
- Core Material: Aluminum
- Core Thickness: 1 1/4
- Core Width: 25 1/8
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4503
- Hazardous Material: No
- Inlet Length (in): 24 15/16
- Inlet Width (in): 1 5/8
- No. Of Rows: 1
- OE Part Number: 8-97328-667-0, 8012195, 8-97328-619-0, 8-97328-669-0, 8012445, 2195, 2445, 8-97209-554-0, 8-97306-328-0, CU2195, CU2445, 8-97209-553-0, 8-97328-617-0
- Oil Cooler (in): 13 1/4 (high-effeciency Concentric Type)
- Outlet Length(in): 24 15/16
- Outlet Width: 1 5/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353029329
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 4 14/16
- Box Length (in): 27 5/16
- Box Weight (lbs): 9
- Box Width (in): 23 9/16
- Core Length: 16 3/4
- Core Material: Aluminum
- Core Thickness: 7/8
- Core Width: 25 1/8
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4503
- Hazardous Material: No
- Inlet Length (in): 24 15/16
- Inlet Width (in): 1 5/8
- No. Of Rows: 1
- OE Part Number: 8-97182-064-0, 8012194, 2194, CU2194
- Outlet Length(in): 24 15/16
- Outlet Width: 1 5/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 1/2 Left
- UPC: 710353030486
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 9/16 Left
- Box Height (in): 8
- Box Length (in): 31
- Box Weight (lbs): 15
- Box Width (in): 28
- Core Length: 18 1/8
- Core Material: Aluminum
- Core Thickness: 15/16
- Core Width: 27 1/16
- Cross-flow/ Down-flow: Down Flow
- Hazardous Material: No
- Inlet Length (in): 27 3/16
- Inlet Width (in): 1 15/16
- No. Of Rows: 1
- OE Part Number: 15179051, 15196385, 52485546, 15162212, 2458, 8-15179-051-0, CU2458, 8-15196-385-0, 8012458
- Oil Cooler (in): 11 1/2 (high-efficiency Plate Type)
- Outlet Length(in): 27 3/16
- Outlet Width: 1 15/16
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M style plastic tanks & Aluminum core;with quick-connect oil cooler fittings.
- Top Hose Fitting (in): 1 3/8 Right
- UPC: 710353031070
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 9/16 Right
- Box Height (in): 8
- Box Length (in): 31
- Box Weight (lbs): 15
- Box Width (in): 29
- Core Length: 18 1/8
- Core Material: Aluminum
- Core Thickness: 15/16
- Core Width: 27 1/16
- Cross-flow/ Down-flow: Down Flow
- Hazardous Material: No
- Inlet Length (in): 27 3/16
- Inlet Width (in): 1 15/16
- No. Of Rows: 1
- OE Part Number: 15162213, 15196386, 2563, 8012563, CU2563, 8-15196-386-0
- Oil Cooler (in): 11 1/2 (high-efficiency Plate Type)
- Outlet Length(in): 27 3/16
- Outlet Width: 1 15/16
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M style plastic tanks & Aluminum core;with quick-connect oil cooler fittings.
- Top Hose Fitting (in): 1 3/8 Right
- UPC: 710353031087
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Cap Included: No
- Core Charge Applicable: No
- Core Height: 16.7500; 425.45
- Core Material: Aluminum
- Core Thickness: 1.2500; 31.75
- Core Width: 24.5; 622.3
- Depth: 1.25
- Fan Included: No
- Height: 16.75
- Inlet Header Length: 24.8125; 630.2375
- Inlet Header Width: 1.5625; 39.6875
- Installation Hardware Included: 1 x Installation Sheet
- Integrated Engine Oil Cooler: No
- Integrated Transmission Oil Cooler: Yes
- Internet Product Code (IPC): 203634FD178
- Item Grade: OEM Standard
- Item has MSDS (SDS): N
- MFG Brand Name: Spectra Premium
- MFG Model # (Series): CU2619
- MFG Name: Spectra Premium Industries
- Mounting Type: Top / Bottom Pin
- Outlet Header Length: 24.8125; 630.2375
- Outlet Header Width: 1.5625; 39.6875
- Package Contents: 1 Radiator 1 Installation Kit
- Product Information Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Product Installation Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Radiator Core Material: Aluminum
- Radiator Inlet Diameter: 1.5
- Radiator Outlet Diameter: 1.5
- Radiator Style: Downflow
- Radiator Tank Material: Plastic
- Supplier Company Name: Spectra Premium Industries
- Tank Material: Plastic
- Transmission Oil Cooler Distance between Fittings: 11.8125
- Transmission Oil Cooler Included: Yes
- Transmission Oil Cooler Type: Concentric
- UPC: 671607747850
- Width: 24.5
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 5 11/16
- Box Length (in): 27 5/16
- Box Weight (lbs): 11
- Box Width (in): 23 3/4
- Core Length: 16 3/4
- Core Material: Aluminum
- Core Thickness: 7/8
- Core Width: 25 1/8
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4503
- Hazardous Material: No
- Inlet Length (in): 24 15/16
- Inlet Width (in): 1 5/8
- No. Of Rows: 1
- Oil Cooler (in): 11 13/16 (high-effeciency Concentric Type)
- Outlet Length(in): 24 15/16
- Outlet Width: 1 5/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 1/2 Left
- Part Description: Isuzu Radiator
More Info Product Specifications- Bottom Hose Fitting (in): 1 1/2 Right
- Box Height (in): 5 1/16
- Box Length (in): 27 5/16
- Box Weight (lbs): 12
- Box Width (in): 26 5/16
- Core Length: 19 11/16
- Core Material: Aluminum
- Core Thickness: 1 1/4
- Core Width: 25 1/8
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4503
- Hazardous Material: No
- Inlet Length: 24 15/16
- Inlet Width: 1 5/8
- No. Of Rows: 1
- Oil Cooler (in): 14 3/4 (high-effeciency Concentric Type)
- Outlet Length: 24 15/16
- Outlet Width: 1 5/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 1/2 Left
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Cap Included: No
- Core Charge Applicable: No
- Core Height: 13.7500; 350.0000
- Core Material: Aluminum
- Core Thickness: 1.0000; 26
- Core Width: 26.3125; 668.3375
- Depth: 1.25
- Fan Included: No
- Height: 13.6875
- Inlet Header Length: 26.375; 669.925
- Inlet Header Width: 1.5625; 39.6875
- Installation Hardware Included: 1 x Installation Sheet
- Integrated Engine Oil Cooler: No
- Integrated Transmission Oil Cooler: Yes
- Internet Product Code (IPC): E1956E7D3F4
- Item Grade: OEM Standard
- Item has MSDS (SDS): N
- MFG Brand Name: Spectra Premium
- MFG Model # (Series): CU1117
- MFG Name: Spectra Premium Industries
- Mounting Type: Pin Mount
- Outlet Header Length: 26.375; 669.925
- Outlet Header Width: 1.5625; 39.6875
- Package Contents: 1 Radiator 1 Installation Kit
- Product Information Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Product Installation Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Radiator Core Material: Aluminum
- Radiator Inlet Diameter: 1.25
- Radiator Outlet Diameter: 1.25
- Radiator Style: Downflow
- Radiator Tank Material: Plastic
- Supplier Company Name: Spectra Premium Industries
- Tank Material: Plastic
- Transmission Oil Cooler Distance between Fittings: 11.8750
- Transmission Oil Cooler Included: Yes
- Transmission Oil Cooler Type: Concentric
- UPC: 671607701401
- Width: 25.875
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Cap Included: No
- Core Charge Applicable: No
- Core Height: 16.5000; 419.1
- Core Material: Copper
- Core Thickness: 1.2500; 31.75
- Core Width: 21.625; 549.275
- Depth: 1.25
- Fan Included: No
- Height: 16.5
- Inlet Header Length: 22.6875; 576.2625
- Inlet Header Width: 1.875; 47.625
- Installation Hardware Included: 1 x Installation Sheet
- Integrated Engine Oil Cooler: No
- Integrated Transmission Oil Cooler: Yes
- Internet Product Code (IPC): AE5FD412E38
- Item Grade: OEM Standard
- Item has MSDS (SDS): N
- MFG Brand Name: Spectra Premium
- MFG Model # (Series): CU1129
- MFG Name: Spectra Premium Industries
- Mounting Type: Flange Mount
- Outlet Header Length: 22.6875; 576.2625
- Outlet Header Width: 1.875; 47.625
- Package Contents: 1 Radiator 1 Installation Kit
- Product Information Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Product Installation Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Radiator Core Material: Copper
- Radiator Inlet Diameter: 1.25
- Radiator Outlet Diameter: 1.25
- Radiator Style: Downflow
- Radiator Tank Material: Brass
- Supplier Company Name: Spectra Premium Industries
- Tank Material: Brass
- Transmission Oil Cooler Distance between Fittings: 12.0000
- Transmission Oil Cooler Included: Yes
- Transmission Oil Cooler Type: Concentric
- UPC: 671607701593
- Width: 21.625
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Cap Included: No
- Core Charge Applicable: No
- Core Height: 16.7500; 425.45
- Core Material: Aluminum
- Core Thickness: 1.0000; 26
- Core Width: 21.9375; 558
- Depth: 1.0
- Fan Included: No
- Height: 16.75
- Inlet Header Length: 23.625; 600.075
- Inlet Header Width: 1.5625; 39.6875
- Installation Hardware Included: 1 x Installation Sheet
- Integrated Engine Oil Cooler: No
- Integrated Transmission Oil Cooler: Yes
- Internet Product Code (IPC): 1167A50CE11
- Item Grade: OEM Standard
- Item has MSDS (SDS): N
- MFG Brand Name: Spectra Premium
- MFG Model # (Series): CU1446
- MFG Name: Spectra Premium Industries
- Mounting Type: Flange Mount
- Outlet Header Length: 23.625; 600.075
- Outlet Header Width: 1.5625; 39.6875
- Package Contents: 1 Radiator 1 Installation Kit
- Product Information Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Product Installation Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Radiator Core Material: Aluminum
- Radiator Inlet Diameter: 1.25
- Radiator Outlet Diameter: 1.25
- Radiator Style: Downflow
- Radiator Tank Material: Plastic
- Supplier Company Name: Spectra Premium Industries
- Tank Material: Plastic
- Transmission Oil Cooler Distance between Fittings: 11.8750
- Transmission Oil Cooler Included: Yes
- Transmission Oil Cooler Type: Concentric
- UPC: 671607704815
- Width: 21.9375
- Part Description: Isuzu Complete Radiator
More Info Product Specifications- Cap Included: No
- Core Charge Applicable: No
- Core Height: 16.7500; 425.45
- Core Material: Aluminum
- Core Thickness: 1.2500; 31.75
- Core Width: 24.1875; 614
- Depth: 1.25
- Fan Included: No
- Height: 16.75
- Inlet Header Length: 25; 635
- Inlet Header Width: 2; 50.8
- Installation Hardware Included: 1 x Installation Sheet
- Integrated Engine Oil Cooler: No
- Integrated Transmission Oil Cooler: Yes
- Internet Product Code (IPC): C141BA24FA2
- Item Grade: OEM Standard
- Item has MSDS (SDS): N
- MFG Brand Name: Spectra Premium
- MFG Model # (Series): CU1571
- MFG Name: Spectra Premium Industries
- Mounting Type: Top Flange / Bottom Pin
- Outlet Header Length: 25; 635
- Outlet Header Width: 2; 50.8
- Package Contents: 1 Radiator 1 Installation Kit
- Product Information Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Product Installation Video Link - URL: http://www.youtube.com/spectrapremiumvideos
- Radiator Core Material: Aluminum
- Radiator Inlet Diameter: 1.5
- Radiator Outlet Diameter: 1.5
- Radiator Style: Downflow
- Radiator Tank Material: Plastic
- Supplier Company Name: Spectra Premium Industries
- Tank Material: Plastic
- Transmission Oil Cooler Diameter: 1
- Transmission Oil Cooler Distance between Fittings: 14.3750
- Transmission Oil Cooler Included: Yes
- Transmission Oil Cooler Type: Concentric
- UPC: 671607706567
- Width: 24.1875
- Part Description: Isuzu Engine Coolant Radiator
More Info Product Specifications- Core Material: Aluminum
- Height: 16 3/4"
- Inlet: 1 1/2"
- Inlet Header: 24 13/16" x 1 9/16"
- Outlet: 1 1/2"
- Outlet Header: 24 13/16" x 1 9/16"
- Row: 1
- Tank Material: Plastic
- Thickness: 1"
- TOC: Concentric; 1 1/8" Diameter; 14 3/4" Distance
- UPC: 671607750225
- Width: 24 5/16"
- Part Description: Isuzu Engine Coolant Radiator
More Info
Featured Isuzu Radiator by Models
