Vehicle Specific
Check if it fits by entering your vehicle infoBrand | CSF |
Part Number | 3108 |
Part Description | Engine Coolant Radiator |
Bottom Hose Fitting (in) | 1 9/16 Right |
Box Height (in) | 8 |
Box Length (in) | 31 |
Box Weight (lbs) | 15 |
Box Width (in) | 29 |
Core Length | 18 1/8 |
Core Material | Aluminum |
Core Thickness | 15/16 |
Core Width | 27 1/16 |
Cross-flow/ Down-flow | Down Flow |
Hazardous Material | No |
Inlet Length (in) | 27 3/16 |
Inlet Width (in) | 1 15/16 |
No. Of Rows | 1 |
UPC | 710353031087 |
OE Part Number | 15162213, 15196386, 2563, 8012563, CU2563, 8-15196-386-0 |
Oil Cooler (in) | 11 1/2 (high-efficiency Plate Type) |
Outlet Length(in) | 27 3/16 |
Outlet Width | 1 15/16 |
Radiator Cap Supplied | No |
Tank Material | Plastic |
Tech Note | O.E.M style plastic tanks & Aluminum core;with quick-connect oil cooler fittings. |
Top Hose Fitting (in) | 1 3/8 Right |
Year Make Model | Trim | Engine |
---|---|---|
2004-2007 Buick Rainier | All Trims | 8 Cyl 5.3L |
2006-2008 Chevrolet Trailblazer | All Trims | 6 Cyl 4.2L |
2006-2008 Chevrolet Trailblazer | All Trims | 8 Cyl 5.3L |
2006-2009 Chevrolet Trailblazer | All Trims | 8 Cyl 6.0L |
2003-2006 Chevrolet Trailblazer EXT | All Trims | 6 Cyl 4.2L |
2003-2006 Chevrolet Trailblazer EXT | All Trims | 8 Cyl 5.3L |
2005-2009 GMC Envoy | All Trims | 6 Cyl 4.2L |
2005-2009 GMC Envoy | All Trims | 8 Cyl 5.3L |
2003-2006 GMC Envoy XL | All Trims | 6 Cyl 4.2L |
2003-2006 GMC Envoy XL | All Trims | 8 Cyl 5.3L |
