Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Walker |
Part Number | 18417 |
Part Description | Soundfx Driver Side Aluminized Steel Oval Direct Fit Exhaust Muffler |
Body Height | 4.250 |
Body Length | 14.000 |
Body Material | Steel |
Body Width | 9.750 |
Exhaust Component Mount Type | Uses Factory Hangers |
Finish | Aluminized |
Grade Type | Regular |
Inlet 1 Inside Diameter | 2.250 |
Inlet 1 Type | Pipe Connection |
Inlet Configuration | Center |
Internet Product Code (IPC) | 78F86D77397 |
Item has MSDS (SDS) | N |
Max Year Covered | 1990 |
MFG Brand Name | Walker Exhaust |
MFG Model # (Series) | 18417 |
MFG Name | Tenneco, Inc |
Min Year Covered | 1985 |
Most Popular Make / Model | Chevrolet Corvette |
Most Popular Year | 1986 |
Muffler Body Height | 4.25 |
Muffler Body Length | 14.0 |
Muffler Body Material | Steel |
Muffler Body Width | 9.75 |
Muffler Color / Finish | Aluminized |
Muffler Inlet | Centered |
Muffler Inlet Connection Type | Pipe Connection |
Muffler Inlet Count | 1 |
Muffler Inlet Diameter (in) | 2.25 |
Muffler Inlet Diameter 2 (in) | 0.0 |
Muffler Inlet Diameter Designation | Inside Diameter |
Muffler Outlet | Offset |
Muffler Outlet Connection Type | Pipe Connection |
Muffler Outlet Count | 2 |
Muffler Outlet Diameter (in) | 2.25 |
Muffler Outlet Diameter Designation | Outside Diameter |
Muffler Overall Length | 31.125 |
Muffler Reversible | No |
Muffler Shape | Oval |
Outlet 1 Outside Diameter | 2.250 |
Outlet 2 Outside Diameter | 2.250 |
Outlet Configuration | Offset |
Overall Length | 31.125 |
Product Grade | Economy |
Reversible | No |
Shape | Oval |
Supplier Company Name | Tenneco, Inc |
Total Part VIO | 81280 |
Universal Or Specific Fit | Specific |
UPC | 086387184175 |
Year Make Model | Trim | Engine |
---|---|---|
1985-1989 Chevrolet Corvette | All Trims | 8 Cyl 5.7L |
1990 Chevrolet Corvette | Base | 8 Cyl 5.7L |
