Vehicle Specific
Check if it fits by entering your vehicle infoBrand | TYC |
Part Number | 2186 |
Part Description | Engine Coolant Radiator |
Bottom Header | 2.54x23.17 |
Core Height | 22.44 |
Core Length | 21.97 |
Core Material | Aluminum |
Core Thickness | 1.26 |
Engine Oil Cooler Included | Yes |
Engine Oil Cooler Type | Plate Oil Cooler(extraposition) |
Eoc Distance (in) | 9.75 |
Eoc Inlet Diameter (in) | 0.37 |
Eoc Inlet Diameter (mm) | 9.5 |
Eoc Inlet Type | Tube fitting |
Eoc Outlet Diameter (in) | 0.37 |
Eoc Outlet Type | Tube fitting |
Fin Count (every 4") | 68 |
Fin Wave Height (in) | 0.35 |
Find Wave Pitch | 3 |
Flow Configuration | Crossflow |
Inlet Connection Type | Hose Clamp |
Inlet Diameter | 1.50 |
No. Of Rows | 1 |
UPC | 762405911847 |
OE Part Number | 52028775AC, CH3010136 |
Outlet Connection Type | Hose Clamp |
Outlet Diameter | 1.77 |
TOC Distance (IN) | 14.37 |
Toc Inlet Diameter (in) | 0.37 |
Toc Inlet Type | Tube fitting |
TOC Outlet Diameter (IN) | 0.37 |
Toc Outlet Type | Tube fitting |
Top Header | 2.54x23.17 |
Total Fin Row Count | 52 |
Total Tube Count | 51 |
Transmission Oil Cooler Included | Yes |
Transmission Oil Cooler Type | Concentric Oil Cooler |
Tube Count (every 4") | 10 |
Tube Width x Height | 32x2 |
Year Make Model | Trim | Engine |
---|---|---|
1997-1998 Dodge Dakota | Base | 6 Cyl 3.9L |
1997-1998 Dodge Dakota | SLT | 6 Cyl 3.9L |
1997-1998 Dodge Dakota | Sport | 6 Cyl 3.9L |
