Vehicle Specific
Check if it fits by entering your vehicle infoBrand | TYC |
Part Number | 1776 |
Part Description | Engine Coolant Radiator |
Bottom Header | 2.02x27.66 |
Core Height (in) | 26.69 |
Core Length (in) | 14.76 |
Core Material | Aluminum |
Core Thickness (in) | 0.63 |
Engine Oil Cooler Included | No |
Fin Count (Every 4"): 64 | 64 |
Fin Wave Height (in) | 0.31 |
Find Wave Pitch | 3.2 |
Flow Configuration | Downflow |
Inlet Connection Type | Hose Clamp |
Inlet Diameter (In) | 1.34 |
No. Of Rows | 1 |
UPC | 762405250502 |
OE Part Number | 19010-P0G-A51 |
Outlet Connection Type | Hose Clamp |
Outlet Diameter (in) | 1.34 |
TOC Distance (IN) | 12.80 |
Toc Inlet Diameter (in) | 0.39 |
Toc Inlet Type | Tube fitting |
TOC Outlet Diameter (IN) | 0.39 |
Toc Outlet Type | Tube fitting |
Top Header | 1.43x27.66 |
Total Fin Row Count | 68 |
Total Tube Count | 67 |
Transmission Oil Cooler Included | Yes |
Transmission Oil Cooler Type | Concentric Oil Cooler |
Tube Count (Every 4"): 10 | 10 |
Tube Width x Height | 16x2 |
Year Make Model | Trim | Engine |
---|---|---|
1997 Acura CL | All Trims | 6 Cyl 3.0L |
1994 Honda Accord | All Trims | 4 Cyl 2.2L |
1995-1997 Honda Accord | All Trims | 6 Cyl 2.7L |
