Vehicle Specific
Check if it fits by entering your vehicle infoBrand | TYC |
Part Number | 13682 |
Part Description | Engine Coolant Radiator |
Bottom Header | 1.83x22.4 |
Core Height (in) | 21.91 |
Core Length (in) | 26.77 |
Core Material | Aluminum |
Core Thickness (in) | 0.87 |
EOC (Yes/No) | No |
Fin Count (Every 4"): 85 | 85 |
Fin Wave Height (in) | 0.18 |
Find Wave Pitch | 2.4 |
Flow Configuration | Crossflow |
Inlet Connection Type | Hose Clamp |
Inlet Diameter (In) | 1.20 |
No. Of Rows | 1 |
UPC | 762405912189 |
OE Part Number | GM3010606, 84448454 |
Outlet Connection Type | Hose Clamp |
Outlet Diameter (in) | 1.20 |
TOC (Yes/No) | No |
Top Header | 1.83x22.4 |
Total Fin Row Count | 93 |
Total Tube Count | 92 |
Tube Count (Every 4"): 17 | 17 |
Tube Width x Height | 22x1.5 |
Year Make Model | Trim | Engine |
---|---|---|
2018-2020 Chevrolet Equinox | All Trims | 4 Cyl 1.5L |
2018-2020 Chevrolet Equinox | All Trims | 4 Cyl 2.0L |
2018-2020 GMC Terrain | All Trims | 4 Cyl 1.5L |
2018-2020 GMC Terrain | All Trims | 4 Cyl 2.0L |
