Vehicle Specific
Check if it fits by entering your vehicle infoBrand | TYC |
Part Number | 13256 |
Part Description | Engine Coolant Radiator |
Bottom Header | 1.71x20.06 |
Core Height | 18.62 |
Core Length | 25.59 |
Core Material | Aluminum |
Core Thickness | 0.87 |
Engine Oil Cooler Included | No |
Fin Count (every 4") | 78 |
Fin Wave Height (in) | 0.20 |
Find Wave Pitch | 2.6 |
Flow Configuration | Crossflow |
Inlet Connection Type | Hose Clamp |
Inlet Diameter | 1.34 |
No. Of Rows | 1 |
UPC | 762405259222 |
OE Part Number | 16041-20314 |
Outlet Connection Type | Hose Clamp |
Outlet Diameter | 1.56 |
Remarks | Plastic Tank Design Only. Verify original radiator on vehicle before ordering |
TOC Distance (IN) | 13.78 |
Toc Inlet Diameter (in) | 0.39 |
Toc Inlet Type | Tube fitting |
TOC Outlet Diameter (IN) | 0.39 |
Toc Outlet Type | Tube fitting |
Top Header | 1.71x20.06 |
Total Fin Row Count | 73 |
Total Tube Count | 72 |
Transmission Oil Cooler Included | Yes |
Transmission Oil Cooler Type | Plate Oil Cooler |
Tube Count (every 4") | 16 |
Tube Width x Height | 22x1.5 |
Year Make Model | Trim | Engine |
---|---|---|
2005-2006 Lexus RX330 | All Trims | 6 Cyl 3.3L |
