26 products about 2016 Mazda CX-5 Cooling Systems, Fans, Radiators & Components found
Product Specifications- Blade Quantity: 5; 7
- Blade Type: Forward Align Fin
- Color/Finish: Black
- Connector Gender: Male
- Connector Quantity: 2
- Connector Type: Male
- Diameter: 330 mm; 330 mm
- Electrical or Mechanical: Electrical
- Fan 1 Blade Quantity: 5
- Fan 1 Diameter: 330 mm
- Fan 2 Blade Quantity: 7
- Fan 2 Diameter: 330 mm
- Fan Blade Material: Plastic
- Fan Quantity: 2
- Fan Rotation: Counterclockwise
- Flat Side On Shaft: Yes
- Grade Type: Standard
- Motor Type: Brushed
- Mounting Bracket Included: No
- OE Part Number: PE0115150, PE0115210, PE0215140, PE0215150, PE011540
- Package Contents: Radiator Fan Assembly
- Package Quantity: 1
- Packaging Type: Box
- Shaft Diameter: 5 mm
- Shroud Included: Yes
- Shroud Material: Plastic
- Terminal Gender: Male
- Terminal Quantity: 2; 2
- UPC: 037495162630
- Voltage: 12 V
- Part Description: 2016 Mazda CX-5 Engine Cooling Fan Assembly
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: New Stretch Fit Belt Replacement Reqd
- Housing: Cast Aluminum
- Impeller Material: Plastic
- Includes Thermostat & Housing: No
- Number of Outlets: 1
- Rotation of Impeller: Standard
- Timing Belt Driven: No
- UPC: 770075712794
- Part Description: 2016 Mazda CX-5 Engine Coolant Standard Water Pump
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: OE Style Design
- Bottom Hose Fitting (in): 1 5/16Centre
- Box Height (in): 6 1/4
- Box Length (in): 31 5/8
- Box Weight (lbs): 9
- Box Width (in): 24 1/8
- Core Length: 16 7/8
- Core Material: Aluminum
- Core Thickness: 5/8
- Core Width: 28 11/16
- Cross-flow/ Down-flow: Down Flow
- Csf Cap Number: 4503
- Hazardous Material: No
- Inlet Length (in): 29 1/2
- Inlet Width (in): 1 5/8
- No. Of Rows: 1
- OE Part Number: PE01 15 200B
- Outlet Length(in): 29 1/2
- Outlet Width: 1 5/8
- Radiator Cap Supplied: No
- Tank Material: Plastic
- Tech Note: O.E.M. style Plastic tanks & Aluminum core.
- Top Hose Fitting (in): 1 5/16 Left
- UPC: 710353037669
- Part Description: 2016 Mazda CX-5 Engine Coolant Radiator
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.25 in
- End 2 Inside Diameter: 1.25 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 90350
- UPC: 770075631408
- Part Description: 2016 Mazda CX-5 Engine Coolant Molded Radiator Hose
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Grade: Aftermarket; Thread Size: M12 X 1,5; Plug (Connector): 2 Pins
- Height [mm]: 19
- Housing Colour: Green
- Length [mm]: 60
- Number of Poles: 2
- Packaging Depth [cm]: 6,8
- Packaging height [cm]: 6,7
- Packaging width [cm]: 4
- Supplementary Article/Info 2: with seal ring
- Supplementary Article/Supplementary Info: with seal
- Thread Size: M12x1,5
- Weight [kg]: 0,03177
- Width [mm]: 19
- Part Description: 2016 Mazda CX-5 Engine Coolant Temperature Sensor
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Housing Material: Aluminum
- Hub Height: 2.52 in
- Hub Pilot Diameter: 1.97 in
- Impeller Material: Plastic
- Impeller Rotation: Standard
- Pulley Type: Flange
- UPC: 083286198784
- Water Pump Drive Type: Serpentine Belt
- Part Description: 2016 Mazda CX-5 Engine Coolant Water Pump
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Cap Type: Flip Top
- Capacity: 850 ML
- Color: Black
- Height: 7.42 In.
- Length: 9.235 In.
- Material: Plastic
- Mount Hole Quantity: 2
- OE Part Number: PE0115351A
- Package Contents: 1 Engine Coolant Reservoir, 1 Cap, 1 Tube
- Pressurized: No
- Shape: Irregular
- UPC: 885484641235
- Part Description: 2016 Mazda CX-5 Engine Coolant Recovery Tank
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Quantity: 1 Piece
- UPC: 072053433647
- Part Description: 2016 Mazda CX-5 Cooling System Tester Adapter
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: 180 Degree; OE Temperature
- By-Pass Flange Diameter: 1.09"
- Depth from Flange: 1.59"
- Design: Bottom By-Pass
- Flange Diameter: 2.05"
- Height from Flange: 0.79"
- Includes Installation Tool: No
- Jiggle Pin/Check Valve: No
- Material: Steel, Copper
- Number of Gaskets: 0
- Number of Seals: 0
- OE Comparison Rating: OE Performance
- Temperature (C): 82
- Temperature (F): 180
- Total Height: 2.38"
- Type: OE Type Thermostat
- UPC: 072053062915
- Part Description: 2016 Mazda CX-5 OE Type Engine Coolant Thermostat
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.25 in
- End 2 Inside Diameter: 1.25 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 193895
- UPC: 770075691747
- Part Description: 2016 Mazda CX-5 Engine Coolant Molded Radiator Hose
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Quantity: 1 Piece
- UPC: 072053020229
- Part Description: 2016 Mazda CX-5 Cooling System Tester Adapter
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: 16 psi Pressure Rating
- Cap Depth: 1.06 in
- Coolant Recovery System: Closed System
- Filler Neck Depth: 16 mm
- Filler Neck Inside Diameter: 32 mm
- Filler Neck Outside Diameter: 43 mm
- OE Comparison Rating: OE Performance
- Pressure Rating: 16 psi
- SAE Pressure Range: 14-18 psi
- Shell Diameter: 66 mm
- UPC: 072053416084
- Part Description: 2016 Mazda CX-5 Engine Coolant Replacement Radiator Cap
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Core Size: 28.6 X 16.73 X 0.63; Manufactured Material: Plastic/Alum; Rows: 1
- Core Size: 28.6 X 16.73 X 0.63
- Manufactured Material: Plastic/Aluminum
- OE Part Number: PE01-15-200A
- Rows: 1
- UPC: 762405257396
- Part Description: 2016 Mazda CX-5 Engine Coolant Radiator
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Terminals: 2
- Part Description: 2016 Mazda CX-5 Engine Coolant Temperature Sensor
Vehicle Fitment- 2016 Mazda CX-5 | Grand Touring | All Engines
- 2016 Mazda CX-5 | Touring | All Engines
- 2016 Mazda CX-5 | Sport | 4 Cyl 2.0L
- 2016 Mazda CX-5 | Sport | 4 Cyl 2.5L
Show More Product Specifications- Color: Black
- Contains Heat Shield: N
- Contains Protective Sleeve: N
- End 1 Inside Diameter: 1 1/4
- End 1 Outside Diameter: 1 5/8
- End 2 Inside Diameter: 1 1/4
- End 2 Outside Diameter: 1 5/8
- Hose Type: Single I.D. Hose
- Material: EPDM
- SAE Specification: SAE J20R4 Class D-1, SAE J1684 Type EC
- Trunk Height: 25 1/2
- UPC: 036687925220
- Part Description: 2016 Mazda CX-5 Engine Coolant Curved Radiator Hose
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Connector Quantity: 1
- Connector Shape: Square
- Terminal Quantity: 2
- Terminal Type: Blade
- UPC: 689604110669
- Part Description: 2016 Mazda CX-5 Coolant Temperature Sender
More Info Vehicle Fitment- 2016 Mazda CX-5 | Sport | 4 Cyl 2.0L
- 2016 Mazda CX-5 | Grand Touring | 4 Cyl 2.5L
- 2016 Mazda CX-5 | Touring | 4 Cyl 2.5L
- 2016 Mazda CX-5 | Sport | 4 Cyl 2.5L
Show More Product Specifications- Notes: Cover
- Air Vent (Bleeder Valve): No
- Bolt Hole Center To Bolt Hole Center: 2.07"; 1.89"; 1.85"; 1.94"
- Bolt Hole Diameter: 0.27"
- Bolt Hole Quantity: 7
- Bolts Included: No
- Color/Finish: Natural
- Flange Thickness: 0.41"
- Height: 2.94"
- Inlet Port Diameter: 1.29"
- Material: Aluminum
- Mount Hole Diameter: 0.27"
- Mount Hole Quantity: 7
- Outlet Diameter: 1.91"
- Thermostat Included: No
- UPC: 889245475930
- Part Description: 2016 Mazda CX-5 Engine Coolant Thermostat Housing
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Serpentine Belt Driven; w/Back Housing
- UPC: 070964177056
- Part Description: 2016 Mazda CX-5 Engine Coolant Water Pump
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Temperature 180 Degrees; Part Replacement Replaces 48478
- Bypass Plate Diameter: 1.09"
- Flange Diameter (Without Seal): 2.05"
- Height from Flange to Bottom: 1.54"
- Height from Flange to Top of Bridge: 0.72"
- OE Part Number: FS1515171, KL0115171A, FS0515171, PE0115171, 91176180, 91176904, F42Z8575BA, F32Z8575A, F62Z8255B, F62Z8255A, F42Z8575A, 1767077E11
- Temperature (F): 180 Degrees
- UPC: 033342054639
- Part Description: 2016 Mazda CX-5 OE Type Engine Coolant Thermostat
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Thermostat Cover
- By-Pass Holes: No
- Material: Plastic
- Number of Bolt Holes: 3
- Number of Gaskets: 0
- Number of Seals: 0
- OE Exact: Yes
- Outlet Inside Diameter 1: 1.11"
- Outlet Outside Diameter 1: 1.29"
- Type: Coolant Outlet
- UPC: 770075766292
- Part Description: 2016 Mazda CX-5 Engine Coolant Water Outlet
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
Product Specifications- Branch Quantity: 0
- Contains Spring: No
- End 1 Inside Diameter: 1.25 in
- End 2 Inside Diameter: 1.25 in
- Material: EPDM
- Modular Hose: No
- Molded: Yes
- Number of Quick Connect Fittings: 0
- OE Part Number: 193022
- UPC: 770075690283
- Part Description: 2016 Mazda CX-5 Engine Coolant Molded Radiator Hose
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
Product Specifications- Fan Clutch Included: No
- Housing Material: Aluminum
- Hub Height: 63.85 mm
- Hub Hole Quantity: 3
- Impeller Material: Composite
- Impeller Rotation: Standard
- Impeller Vane Quantity: 7
- Includes Back Housing: No
- Mounting Hole Quantity: 7
- Pulley Included: No
- Water Pump Drive Type: Serpentine Belt
- Part Description: 2016 Mazda CX-5 Engine Coolant Water Pump
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Notes: Pressure Rating 16 psi
- Cap Depth: 1.06"
- Filler Neck Depth: 0.63"
- Filler Neck Inside Diameter: 1.26"
- Filler Neck Outside Diameter: 1.69"
- OE Part Number: E9SZ8100A, E9SH8100AA, F42Z8100A, 5L548100AA, F87H8100AA, F02Z8100A, M04495805, 4495805, MO4495805, 25330-0W000, 25330-3K000, 25330-1P000, 25330-2E000, 25330-1R000, 53303Z000, 253302D090, 53303K000, 253302E100, 53301P000, 253302E001, 533039100, 25330C2000
- Pressure: 16 psi
- Shell Diameter: 2.59"
- Type: Closed System
- UPC: 033342001336
- Part Description: 2016 Mazda CX-5 Engine Coolant Radiator Cap
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Attachment Method: Screw-in
- Color/Finish: Metal, Plastic
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangular
- Connector Type: Plug In
- Hardware Included: No
- Mounting Hardware Included: No
- Notes: Complete Assembly
- OE Part Number: 89422-35010
- Terminal Gender: Male
- Terminal Quantity: 2
- Terminal Type: Blade
- UPC: 841266045523
- Voltage [V]: 12
- Part Description: 2016 Mazda CX-5 Engine Coolant Temperature Sensor
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | All Engines
Product Specifications- Notes: Pressure Rating 16 psi
- Cap Depth: 1.41"
- Filler Neck Depth: 0.63"
- Filler Neck Inside Diameter: 1.61"
- Filler Neck Outside Diameter: 1.69"
- Pressure: 16 psi
- Shell Diameter: 2.2"
- Type: Optional System
- UPC: 033342074613
- Part Description: 2016 Mazda CX-5 Engine Coolant Radiator Cap
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
Product Specifications- Freight Class: 70
- UPC: 333421498164
- Part Description: 2016 Mazda CX-5 Engine Coolant Temperature Sensor
More Info Vehicle Fitment- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.0L
- 2016 Mazda CX-5 | All Trims | 4 Cyl 2.5L
