Notes: with 22 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 28 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 73.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 224.0
Resistance Ohms Full: 19.0
Strainer Included: Yes
System Pressure: 49 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604061725
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2001 Dodge Dakota Fuel Pump Module Assembly
Notes: with 24 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 27 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 51.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 220.0
Resistance Ohms Full: 20.0
Strainer Included: Yes
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Pin
UPC: 689604218655
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2001 Dodge Dakota Fuel Pump Module Assembly
Notes: with 22 Gallon Tank;w/22 Gallon Tank;Includes Fuel Pump, Fuel Pressure Regulator, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal
Average Current Draw(A): 8
Average Flow Rating(GPH): 30.4
Connector Gender: Female
Connector Quantity: 1
Connector Shape: Rectangle
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Fuel Type: Rollervane
Gasket or Seal Included: Yes
Gasket Or Seal Material: FKM
Grade Type: Regular
Housing Material: POM
In Tank or External: In Tank
Inlet Size: 0.433
Inlet Type: Strainer
Installation Warnings: No
Internal or External: Internal
Internal Or External Strainer: Internal
Lock Ring Included: No
Maximum Free Flow (GPH): 52.2
Maximum Pump Pressure (PSI): 52.8
Minimum Free Flow (GPH): 42.2
Minimum Pump Pressure (PSI): 48.7
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect
Product Height (in): 5.98
Product Length (in): 17.13
Product Width (in): 8.94
Pump Type: Rollervane
Regulator Included: Yes
Resistance Ohms Empty: 224
Resistance Ohms Full: 24
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845131270
Voltage: 12V
Weight (lbs): 3.67
Wire Harness Included: No
Part Description: 2001 Dodge Dakota Fuel Pump Module Assembly
Notes: Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal;Drop Tank and clean before replacing fuel pump;w/24 Gallon Tank
Average Current Draw(A): 9
Average Flow Rating(GPH): 48
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Rectangle
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Fuel Type: Turbine
Gasket or Seal Included: Yes
Gasket Or Seal Material: NBR
Grade Type: Performance
Housing Material: Aluminium
In Tank or External: In Tank
Inlet Size: 0.433
Inlet Type: Strainer
Installation Warnings: No
Internal or External: Internal
Internal Or External Strainer: External and Internal
Lock Ring Included: No
Maximum Free Flow (GPH): 65
Maximum Pump Pressure (PSI): 100
Minimum Free Flow (GPH): 55
Minimum Pump Pressure (PSI): 80
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect
Product Height (in): 5.71
Product Length (in): 10.43
Product Width (in): 9.84
Pump Type: Turbine
Regulator Included: Yes
Resistance Ohms Empty: 220
Resistance Ohms Full: 20
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845131393
Voltage: 12V
Weight (lbs): 3.24
Wire Harness Included: No
Part Description: 2001 Dodge Dakota Fuel Pump Module Assembly
