Replacement and OEM Parts for Dodge Dart Piston
Select your vehicle for the best product fit
  • Select Vehicle by Model
  • Select Vehicle by VIN
Select Make
Select Model
Select Year
or

Dodge Dart Piston

< Back to View All
Crankshafts, Pistons, Rings & Connecting Rods
  • Department
  • Brands
  • Prices

15 Products found

Show Item:
  • 30
  • 60
  • 90
Sort by:
Recommended
Filter
Sort
View by
  • Sealed Power Flat Top Piston for Dodge Dart - 285AP

    Sealed Power® Flat Top Piston for Dodge Dart

    PartNumber: 285AP
    Product Specifications
    • Bore: 99.2200 mm
    • Compression Distance: 1.720"
    • Head Illustration: 26
    • Material: Cast
    • Minimum Clearance: 0.001 @ 2.660 from top of head
    • Pin Diameter: 24.999 mm
    • Pin Offset: 1.524 mm
    • Ring 1 Qty: 2
    • Ring 1 Width: 5/64"
    • Ring 2 Qty: 1
    • Ring 2 Width: 3/16"
    • Size: Standard
    • UPC: 614046950078
    • Part Description: Dodge Dart Flat Top Piston
    More Info
    $20.14
  • Sealed Power Flat Top Piston for Dodge Dart - 285AP30

    Sealed Power® Flat Top Piston for Dodge Dart

    PartNumber: 285AP30
    Product Specifications
    • Bore: 3.9063"
    • Compression Distance: 1.720"
    • Head Illustration: 26
    • Material: Cast
    • Minimum Clearance: 0.001 @ 2.660 from top of head
    • Oversize: 0.030"
    • Pin Diameter: 24.999 mm
    • Pin Offset: 1.524 mm
    • Ring 1 Qty: 2
    • Ring 1 Width: 5/64"
    • Ring 2 Qty: 1
    • Ring 2 Width: 3/16"
    • UPC: 614046950115
    • Part Description: Dodge Dart Flat Top Piston
    More Info
    $20.14
  • Sealed Power Flat Top Piston for Dodge Dart - 285AP40

    Sealed Power® Flat Top Piston for Dodge Dart

    PartNumber: 285AP40
    Product Specifications
    • Bore: 99.2200 mm
    • Compression Distance: 1.720"
    • Head Illustration: 26
    • Material: Cast
    • Minimum Clearance: 0.001 @ 2.660 from top of head
    • Oversize: 0.040"
    • Pin Diameter: 0.9842"
    • Pin Offset: 1.524 mm
    • Ring 1 Qty: 2
    • Ring 1 Width: 5/64"
    • Ring 2 Qty: 1
    • Ring 2 Width: 3/16"
    • UPC: 614046950139
    • Part Description: Dodge Dart Flat Top Piston
    More Info
    $20.01
  • Sealed Power Flat Top Piston for Dodge Dart - 285AP20

    Sealed Power® Flat Top Piston for Dodge Dart

    PartNumber: 285AP20
    Product Specifications
    • Bore: 3.9063
    • Compression Distance: 1.720
    • Material: Cast
    • Pin Diameter: 24.999
    • Pin Offset: 0.06
    • Ring 1 Quantity: 2
    • Ring 1 Width: 5/64
    • Ring 2 Quantity: 1
    • Ring 2 Width: 3/16
    • UPC: 614046950092
    • Part Description: Dodge Dart Flat Top Piston
    More Info
    $20.01
  • OEM (Genuine) Dodge Dart Piston-B-Size

    PartNumber: 68165766AB
    OEM Dodge Dart Piston-B-Size - 68165766AB
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 11.4 x 7.0 x 7.4 inches
    • Item Weight: 2.80 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 68165766AA
    • Part Description: Dodge Dart Piston-B-Size
    More Info
    $93.51 MSRP: $143.00
    You Save: $49.49 (35%)
  • OEM (Genuine) Dodge Dart Piston-B-Size

    PartNumber: 5048640AA
    OEM Dodge Dart Piston-B-Size - 5048640AA
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 11.4 x 7.0 x 7.0 inches
    • Item Weight: 2.60 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 68191814AA, 5048542AA
    • Part Description: Dodge Dart Piston-B-Size
    More Info
    $131.91 MSRP: $198.00
    You Save: $66.09 (34%)
  • OEM (Genuine) Dodge Dart Piston-A-Size

    PartNumber: 5048639AA
    OEM Dodge Dart Piston-A-Size - 5048639AA
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 11.3 x 7.1 x 7.3 inches
    • Item Weight: 5.10 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 68191813AA, 5048541AA
    • Part Description: Dodge Dart Piston-A-Size
    More Info
    $77.38 MSRP: $114.00
    You Save: $36.62 (33%)
  • OEM (Genuine) Dodge Dart Piston-C-Size

    PartNumber: 5048641AA
    OEM Dodge Dart Piston-C-Size - 5048641AA
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 10.8 x 7.0 x 7.2 inches
    • Item Weight: 2.80 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 68191815AA, 5048543AA
    • Part Description: Dodge Dart Piston-C-Size
    More Info
    $130.80 MSRP: $197.00
    You Save: $66.20 (34%)
  • OEM (Genuine) Dodge Dart Piston-C-Size

    PartNumber: 68165768AB
    OEM Dodge Dart Piston-C-Size - 68165768AB
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 12.8 x 6.0 x 4.7 inches
    • Item Weight: 2.30 Pounds
    • Fitment Type: Direct Replacement
    • Part Description: Dodge Dart Piston-C-Size
    More Info
    $87.13 MSRP: $131.00
    You Save: $43.87 (34%)
  • Sealed Power Engine Piston for Dodge Dart - 405P

    Sealed Power® Engine Piston for Dodge Dart

    PartNumber: 405P
    Product Specifications
    • Bore: 101.6000
    • Bore (Inch): 4.0000
    • Compression Distance: 1.576
    • Head Illustration: 28
    • Head Type: Recessed Head .070 deep x 3.140 dia. - 8.0:1 C.R.
    • Minimum Clearance: 0.001 @ 2.320 from top of head
    • Note 1: Standard Size
    • Part Material: Cast
    • Pin Diameter: 24.999
    • Pin Diameter (Inch): 0.9842
    • Pin Offset: 1.524
    • Pin Offset (Inch): 0.06
    • Ring 1 Qty: 2
    • Ring 1 Width: 5/64
    • Ring 2 Qty: 1
    • Ring 2 Width: 3/16
    • Standard Size: Standard
    • UPC: 724956350292
    • Part Description: Dodge Dart Engine Piston
    More Info
  • OEM (Genuine) Dodge Dart Piston-A-Size

    PartNumber: 68165765AB
    OEM Dodge Dart Piston-A-Size - 68165765AB
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 10.8 x 7.0 x 6.9 inches
    • Item Weight: 2.90 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 68165765AA
    • Part Description: Dodge Dart Piston-A-Size
    More Info
  • OEM (Genuine) Dodge Dart Piston-A-Size

    PartNumber: 68149734AA
    OEM Dodge Dart Piston-A-Size - 68149734AA
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 13.6 x 6.1 x 4.7 inches
    • Item Weight: 1.80 Pounds
    • Fitment Type: Direct Replacement
    • Part Description: Dodge Dart Piston-A-Size
    More Info
  • Sealed Power Engine Piston for Dodge Dart - 428P

    Sealed Power® Engine Piston for Dodge Dart

    PartNumber: 428P
    Product Specifications
    • Bore: 102.5000
    • Compression Distance: 1.829
    • Head Illustration: 189
    • Head Type: Flat Head w/4 valve reliefs - 10.2:1 C.R.
    • Minimum Clearance: 0.0015 @ 2.640 from top of head
    • Part Material: Cast
    • Pin Diameter: 24.999
    • Pin Offset: 1.524
    • Ring 1 Qty: 2
    • Ring 1 Width: 5/64
    • Ring 2 Qty: 1
    • Ring 2 Width: 3/16
    • UPC: 724956352234
    • Part Description: Dodge Dart Engine Piston
    More Info
  • OEM (Genuine) Dodge Dart Piston-B-Size

    PartNumber: 68149735AA
    OEM Dodge Dart Piston-B-Size - 68149735AA
    Product Specifications
    • Other Names: Piston
    • Item Dimensions: 11.2 x 4.8 x 4.6 inches
    • Item Weight: 1.90 Pounds
    • Fitment Type: Direct Replacement
    • Part Description: Dodge Dart Piston-B-Size
    More Info
  • OEM (Genuine) Dodge Dart Piston-C-Size

    PartNumber: 68149736AA
    OEM Dodge Dart Piston-C-Size - 68149736AA
    Product Specifications
    • Other Names: Bearing, Piston
    • Item Dimensions: 11.3 x 4.9 x 4.8 inches
    • Item Weight: 1.90 Pounds
    • Fitment Type: Direct Replacement
    • Part Description: Dodge Dart Piston-C-Size
    More Info

About Dodge Dart Piston

Dodge Dart lasted for four generations. Each generation of the Dodge Dart was a great success in competing against other models. During the development of the brand, many popular parts have been built, such as the piston. The Dodge Dart piston is made and comes in different forms as well as materials to withstand all the pressure from combustion. A bad piston can lead to bad fuel economy, a decline in engine performance, and oil consumption.
The Dodge Dart functions quite well in the beginning. However, the old piston might lead to poor functions and unpleasant driving experiences after years of usage. The pistons help to provide each cylinder with combustion which in return will allow for the motion of the car. They help to transfer the expanding gas in the cylinder to turn the crankshaft using mechanical force. The crucial parts of a piston include a piston (the quantity depending on the number of cylinders), a connecting rod, an oil control ring, compression rings, wrist pins, bearing caps, bearings, set screws, and locking plates. Our large assortment covers most of the classic Dodge Dart cars. We provide considerate and nice Dodge Dart services to car buyers online.
