Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Outlet Outside Diameter: 0.375''
Outlet Quantity: 1
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 180.0
Resistance Ohms Full: 10.0
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604284049
Vapor Pressure Sensor: No
Part Description: 2015 Ford Taurus Passenger Side Fuel Pump Module Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 70 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: No
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Lock Ring Included: No
Maximum Pressure: 95.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 180.0
Resistance Ohms Full: 10.0
Strainer Included: Yes
System Pressure: 55 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604241561
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2015 Ford Taurus Fuel Pump Module Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: No
In Tank or External: In Tank
Item Grade: Standard Replacement
Outlet Outside Diameter: 0.500''
Outlet Quantity: 1
Outlet Type: Quick Connect
Package Contents: Fuel Transfer Unit with Float Arm, Instruction Sheet
Regulator Included: No
Resistance Ohms Empty: 180.0
Resistance Ohms Full: 10.0
Strainer Included: No
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Blade
UPC: 689604265154
Vapor Pressure Sensor: No
Part Description: 2015 Ford Taurus Left Fuel Tank Sending Unit
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 66 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: No
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Lock Ring Included: No
Maximum Pressure: 95.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: Yes
Resistance Ohms Empty: 180.0
Resistance Ohms Full: 10.0
Strainer Included: Yes
System Pressure: 55 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604241547
Vapor Pressure Sensor: No
Voltage: 12.0 VDC
Part Description: 2015 Ford Taurus Passenger Side Fuel Pump Module Assembly
Notes: Includes Fuel Pump, Fuel Pressure Regulator, Sending Unit, Float, Fuel Reservoir and Fuel Strainer,AWD,Engine VIN:8,Naturally Aspirated;8 AWD, Naturally Aspirated, Right Side
Average Current Draw(A): 7.5
Average Flow Rating(GPH): 48
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Trapezoid
Country of Orign: China
Fuel Filter Included: Yes
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Gasket or Seal Included: No
Gasket Or Seal Material: NBR
Grade Type: Performance
Housing Material: POM
In Tank or External: In Tank
Inlet Size: 0.433
Inlet Type: Strainer
Installation Warnings: No
Internal Or External Strainer: Internal
Lock Ring Included: No
Maximum Pump Pressure (PSI): 60
Minimum Pump Pressure (PSI): 50
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect
Product Height (in): 5.98
Product Length (in): 9.84
Product Width (in): 9.84
Pump Type: Turbine
Regulator Included: Yes
Resistance Ohms Empty: 180
Resistance Ohms Full: 10
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845116253
Voltage: 12V
Weight (lbs): 2.9
Wire Harness Included: No
Part Description: 2015 Ford Taurus Fuel Pump Module Assembly
