Notes: RPO Code NL1;RPO Code NF4 or NF2;with Federal Emission System;with Cutaway Chassis;with 35 Gallon Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 24 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 109.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
System Pressure: 62 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060964
Vapor Pressure Sensor: No
Voltage: 13.0 VDC
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: w/GVW under 8500lb; w/o Fitting for Take Off Fuel Line (RPO Code: 7T6); Includes Wiring Harness, Terminals & Tank Seal; w/2 Electrical Connectors
Gasket Included: Y
Hazardous Material: No
Inlet Count: 1
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Free Flow Rate (gph): 65
Maximum Pressure Rate (psi): 100
Minimum Free Flow Rate (gph): 55
Minimum Pressure Rate (psi): 80
Outlet Count: 1
Outlet Size: 3/8"
Outlet Type: Quick Connect, Return Line
Package Contents: Pump & Kit
Package Quantity: 1
UPC: 080044516323
Warranty: Lifetime Limited Warranty
Part Description: 2002 Chevrolet Express 3500 In-Tank Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: Except Cutaway Chassis;Strainer is Inside the Module Assembly;with 35 Gallon Tank;RPO Code NL1;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.;Actual OE Part; w/o 55 Gallon Fuel Tank
Fuel Level Sender Assembly Included: Yes
Fuel Type: Diesel
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060186
Vapor Pressure Sensor: No
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 6.5L
Notes: Exc. Calif.;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer, Tank Seal and Upgraded Wiring Harness;Wiring Harness replacement recommended;w/Fuel Fitting For Auxiliary Power Units
Average Current Draw(A): 7.5
Average Flow Rating(GPH): 33
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Rectangle
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Fuel Type: Turbine
Gasket or Seal Included: Yes
Gasket Or Seal Material: NBR
Grade Type: Regular
Housing Material: POM
In Tank or External: In Tank
Inlet Size: 5/16
Inlet Type: Quick Connect
Installation Warnings: No
Internal or External: Internal
Lock Ring Included: No
Maximum Free Flow (GPH): 55.5
Maximum Pump Pressure (PSI): 145
Minimum Free Flow (GPH): 45
Minimum Pump Pressure (PSI): 87
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect
Product Height (in): 5.35
Product Length (in): 16.73
Product Width (in): 14.02
Pump Type: Turbine
Regulator Included: No
Resistance Ohms Empty: 40
Resistance Ohms Full: 250
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845125842
Voltage: 12V
Weight (lbs): 2.51
Wire Harness Included: Yes
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: RPO Code NE7;with 55 Gallon Tank;Strainer is Inside the Module Assembly;with Cutaway Chassis;55 Gallon Fuel Tank; Actual OE Part;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Fuel Level Sender Assembly Included: Yes
Fuel Type: Diesel
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060193
Vapor Pressure Sensor: No
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 6.5L
Notes: with Federal Emission System;RPO Code NF4 or NF2;RPO Code NE7;with Cutaway Chassis;with 55 Gallon Tank;without Fitting for Take-Off Fuel Line;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 24 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 109.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
System Pressure: 62 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060377
Vapor Pressure Sensor: No
Voltage: 13.0 VDC
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: LPG Conversion;w/2 Electrical Connectors;w/o Fuel Fitting For Auxiliary Power Units;Exc. Natural Gas;w/Module Code VAY;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer, Upgraded Wiring Harness and Tank Seal
Average Current Draw(A): 8.5
Average Flow Rating(GPH): 41
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Rectangle
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: Yes
Fuel Type: Turbine
Gasket or Seal Included: Yes
Gasket Or Seal Material: NBR
Grade Type: Regular
Housing Material: POM
In Tank or External: In Tank
Inlet Size: 5/16
Inlet Type: Quick Connect
Installation Warnings: No
Internal or External: Internal
Lock Ring Included: No
Maximum Free Flow (GPH): 63.5
Maximum Pump Pressure (PSI): 145
Minimum Free Flow (GPH): 52.8
Minimum Pump Pressure (PSI): 87
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect
Product Height (in): 6.3
Product Length (in): 14.17
Product Width (in): 7.52
Pump Type: Turbine
Regulator Included: No
Resistance Ohms Empty: 40
Resistance Ohms Full: 250
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845129826
Voltage: 12V
Weight (lbs): 2.23
Wire Harness Included: Yes
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: RPO Code NA1, NF4 or NF2;with Federal Emission System;with California Emission System;Except Cutaway Chassis;Except Auxiliary Fuel Fitting;RPO Code NB6 or NC1;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 24 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Maximum Pressure: 131.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
System Pressure: 62 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604083871
Vapor Pressure Sensor: Yes
Voltage: 13.0 VDC
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: w/o Fuel Fitting For Auxiliary Power Units;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer, Upgraded Wiring Harness and Tank Seal;w/1 Electrical Connector
Average Current Draw(A): 7.3
Average Flow Rating(GPH): 35.6
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Rectangle
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Fuel Type: Turbine
Gasket or Seal Included: Yes
Gasket Or Seal Material: NBR
Grade Type: Regular
Housing Material: POM
In Tank or External: In Tank
Inlet Size: 5/16
Inlet Type: Quick Connect
Installation Warnings: No
Internal or External: Internal
Lock Ring Included: No
Maximum Free Flow (GPH): 63.5
Maximum Pump Pressure (PSI): 145
Minimum Free Flow (GPH): 52.8
Minimum Pump Pressure (PSI): 87
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect
Product Height (in): 6.3
Product Length (in): 13.78
Product Width (in): 7.52
Pump Type: Turbine
Regulator Included: No
Resistance Ohms Empty: 40
Resistance Ohms Full: 250
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845129772
Voltage: 12V
Weight (lbs): 2.19
Wire Harness Included: Yes
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: with California Emission System;RPO Code NL1;with 35 Gallon Tank;RPO Code NC1;with Cutaway Chassis;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 24 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Maximum Pressure: 109.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
System Pressure: 62 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060957
Vapor Pressure Sensor: Yes
Voltage: 13.0 VDC
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: without Evaporative Emission;Except Cutaway Chassis;Module has 1 Electrical Connector(s);RPO Code NA4, NF4 or NF2;without Fitting for Take-Off Fuel Line;with Federal Emission System;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 32 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 109.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
System Pressure: 62 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060353
Vapor Pressure Sensor: No
Voltage: 13.0 VDC
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 8.1L
Notes: RPO Code EVA;without Fitting for Take-Off Fuel Line;with California Emission System;RPO Code NC1;with Evaporative Emission;Except Cutaway Chassis;Module has 2 Electrical Connector(s);Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 32 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: Internal
Item Grade: Standard Replacement
Maximum Pressure: 109.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Type: Electric
Regulator Included: No
Resistance Ohms Empty: 40.0
Resistance Ohms Full: 250.0
Strainer Included: Yes
System Pressure: 62 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Blade
UPC: 689604060360
Vapor Pressure Sensor: Yes
Voltage: 13.0 VDC
Part Description: 2002 Chevrolet Express 3500 Fuel Pump Module Assembly
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 5.7L
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 2
Flow Rating: 32 gph
Fuel Type: Diesel
Gasket or Seal Included: No
In Tank or External: External
Inlet Fitting Thread Size: M16-1.5
Inlet Type: Female Threaded
Item Grade: Standard Replacement
Outlet Fitting Thread Size: M16 - 1.5
Outlet Type: Female Threaded
Pump Type: Electric
Strainer Included: No
System Pressure: 7 psi
Terminal Gender: Female
Terminal Quantity: 2
Terminal Type: Pin
UPC: 689604032633
Voltage: 12 VDC
Wiring Harness Included: No
Part Description: 2002 Chevrolet Express 3500 In Line Electric Fuel Pump
More Info
Vehicle Fitment
2002 Chevrolet Express 3500 | All Trims | 8 Cyl 6.5L
