Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 8
Flow Rating: 40 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Flex
Gasket or Seal Included: Yes
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 102.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 3
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 44.0
Resistance Ohms Full: 444.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 8
Terminal Type: Pin
UPC: 689604233689
Voltage: 12.0 VDC
Part Description: 2000 Ford Ranger Fuel Pump And Sender Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 5
Flow Rating: 40 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Flex
Gasket or Seal Included: Yes
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 94.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 3
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 7.0
Resistance Ohms Full: 140.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 8
Terminal Type: Pin
UPC: 689604233719
Voltage: 12.0 VDC
Part Description: 2000 Ford Ranger Fuel Pump And Sender Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 5
Flow Rating: 40 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 94.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 15.0
Resistance Ohms Full: 160.0
Strainer Included: Yes
System Pressure: 58 psi
Terminal Gender: Male
Terminal Quantity: 8
Terminal Type: Pin
UPC: 689604233498
Voltage: 12.0 VDC
Part Description: 2000 Ford Ranger Fuel Pump And Sender Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 5
Flow Rating: 28 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 87.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 3
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 15.0
Resistance Ohms Full: 162.0
Strainer Included: Yes
System Pressure: 65 psi
Terminal Gender: Male
Terminal Quantity: 7
Terminal Type: Pin
UPC: 689604233849
Voltage: 12.0 VDC
Part Description: 2000 Ford Ranger Fuel Pump And Sender Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 28 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: No
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 94.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 3
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 15.0
Resistance Ohms Full: 160.0
Strainer Included: Yes
System Pressure: 65 psi
Terminal Gender: Male
Terminal Quantity: 7
Terminal Type: Pin
UPC: 689604233856
Voltage: 12.0 VDC
Part Description: 2000 Ford Ranger Fuel Pump And Sender Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 18 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 80.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Type: Hose
Pump Type: Electric
Strainer Included: Yes
System Pressure: 45 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Blade
UPC: 689604139509
Voltage: 12.0 VDC
Wiring Harness Included: No
Part Description: 2000 Ford Ranger Fuel Pump And Strainer Set
Notes: To Be Used With OE Style Modules Only;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 32 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Pressure: 103.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Hose Bead
Pump Type: Electric
Strainer Included: No
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Pin
UPC: 689604215173
Voltage: 12 VDC
Wiring Harness Included: Yes
Part Description: 2000 Ford Ranger In Tank Electric Fuel Pump
Notes: Includes Fuel Pump, Sending Unit, Float, Fuel Pressure Regulator, Fuel Strainer and Tank Seal,126.0;Includes Fuel Pump, Sending Unit, Float, Fuel Pressure Regulator, Fuel Strainer and Tank Seal,U,126.0,GAS
Gasket or Seal Included: Yes
Height (in.): 7.5
Inlet Type: Strainer
Length (in.): 16
Life Cycle Status Code: Available to Order
Maximum Free Flow (GPH): 55
Maximum Pump Pressure (PSI): 105
Minimum Free Flow (GPH): 45
Minimum Pump Pressure (PSI): 85
Outlet Size: 3/8
Outlet Type: Quick Connect, Return Line
Package Contents: Pump & Kit
UPC: 072845112811
Weight (lbs.): 3.1
Width (in.): 11
Part Description: 2000 Ford Ranger Electric Fuel Pump
Notes: Includes Fuel Pump, Sending Unit, Float, Fuel Pressure Regulator, Fuel Strainer and Tank Seal,112.0;Includes Fuel Pump, Sending Unit, Float, Fuel Pressure Regulator, Fuel Strainer and Tank Seal,U,112.0,GAS
Gasket or Seal Included: Yes
Height (in.): 7
Inlet Type: Strainer
Length (in.): 14
Life Cycle Status Code: Available to Order
Maximum Free Flow (GPH): 50
Maximum Pump Pressure (PSI): 100
Minimum Free Flow (GPH): 45
Minimum Pump Pressure (PSI): 80
Outlet Size: 3/8
Outlet Type: Quick Connect, Return Line
Package Contents: Pump & Kit
UPC: 072845112705
Weight (lbs.): 3
Width (in.): 10
Part Description: 2000 Ford Ranger Electric Fuel Pump
