Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 29 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 73.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 16.0
Resistance Ohms Full: 160.0
Strainer Included: Yes
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Pin
UPC: 689604198063
Voltage: 12.0 VDC
Part Description: 1999 Ford F-150 Fuel Pump And Sender Assembly
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 29 gph
Fuel Level Sender Assembly Included: Yes
Fuel Type: Gas
Gasket or Seal Included: Yes
Inlet Type: Strainer
Internal or External Strainer: External
Item Grade: Standard Replacement
Maximum Pressure: 73.0 PSI
Outlet Outside Diameter: 0.375''
Outlet Quantity: 2
Outlet Type: Quick Connect
Pump Location: In Tank
Pump Type: Electric
Resistance Ohms Empty: 16.0
Resistance Ohms Full: 160.0
Strainer Included: Yes
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: Pin
UPC: 689604194485
Voltage: 12.0 VDC
Part Description: 1999 Ford F-150 Fuel Pump And Sender Assembly
Notes: To Be Used With OE Style Modules Only;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 6
Flow Rating: 32 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Pressure: 103.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Hose Bead
Pump Type: Electric
Strainer Included: No
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Pin
UPC: 689604215173
Voltage: 12 VDC
Wiring Harness Included: Yes
Part Description: 1999 Ford F-150 In Tank Electric Fuel Pump
Notes: Includes Fuel Pump, Sending Unit, Float, Fuel Strainer and Tank Seal,4WD,120.0;Includes Fuel Pump, Sending Unit, Float, Fuel Strainer and Tank Seal,4WD,120.0,Naturally Aspirated
Average Current Draw(A): 7
Average Flow Rating(GPH): 34
Connector Gender: Male
Connector Quantity: 1
Connector Shape: Round
Country of Orign: China
Fuel Filter Included: No
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: No
Gasket or Seal Included: Yes
Gasket Or Seal Material: NBR
In Tank or External: In Tank
Inlet Size: 0.433
Inlet Type: Strainer
Installation Warnings: No
Internal Or External Strainer: External
Lock Ring Included: No
Maximum Pump Pressure (PSI): 90
Minimum Pump Pressure (PSI): 70
Mounting Hardware Included: No
Negative Ground: No
Outlet Quantity: 1
Outlet Size: 3/8
Outlet Type: Quick Connect, Return Line
Product Height (in): 6.69
Product Length (in): 15.35
Product Width (in): 6.69
Pump Type: Turbine
Regulator Included: No
Resistance Ohms Empty: 16
Resistance Ohms Full: 160
Strainer Included: Yes
Terminal Gender: Male
Terminal Quantity: 4
Terminal Type: PIN
UPC: 00072845112309
Voltage: 12V
Weight (lbs): 2.9
Wire Harness Included: No
Part Description: 1999 Ford F-150 Electric Fuel Pump
