Dorman® Fuel Tank Sending Unit for 1993 Dodge W150
PartNumber: 2630336Product Specifications- Connector Color: White
- Connector Gender: Female
- Connector Shape: Flat Plug
- Height: 370 mm
- Housing Length: 256 mm
- Housing Material: Plastic (Polyoxymethylene)
- Housing Width: 126 mm
- Inlet Diameter: 7.9 mm
- Inlet Type: Male
- Lock Ring Included: No
- Maximum Flow Rating: 110 LPH
- Maximum Pressure: 0.85 MPA
- OE Part Number: 4762539, 52017638, 4728730, 52017634, 52017814, 52004836
- Outlet Diameter: 9.5 mm
- Outlet Quantity: 1
- Outlet Type: Male
- Seal Included: Yes
- Terminal Gender: Female
- Terminal Quantity: 5
- Terminal Type: Bullet
- Universal Or Specific Fit: Specific
- UPC: 747214303366
- Width: 6.35 mm
- Wire Gauge Measurement: 1.5 AWG
- Wire Quantity: 4
- Part Description: 1993 Dodge W150 Fuel Tank Sending Unit
Vehicle Fitment- 1993 Dodge W150 | All Trims | All Engines
$135.99
Delphi® Fuel Pump Module Assembly for 1993 Dodge W150
PartNumber: FG0372Product Specifications- Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 8
- Flow Rating: 42 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 15.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 103.0
- Resistance Ohms Full: 4.0
- Strainer Included: Yes
- System Pressure: 44 psi
- Terminal Gender: Male
- Terminal Quantity: 5
- Terminal Type: Pin
- UPC: 689604120620
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: 1993 Dodge W150 Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge W150 | All Trims | 6 Cyl 3.9L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.2L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
$130.83
Autobest® Fuel Pump Module Assembly for 1993 Dodge W150
PartNumber: F3058AProduct Specifications- Notes: with 22 Gallon Tank;w/Return System;Pump Assembly Does Not Include Pressure Regulator;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal.Fuel Sensor Design Provides Resistance To Corrosive Fuel Blends And Additives.
- Average Current Draw(A): 8
- Average Flow Rating(GPH): 46.3
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.504
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Lock Ring Included: No
- Maximum Pump Pressure (PSI): 116
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 3/8
- Outlet Type: Quick Connect
- Product Height (in): 6.81
- Product Length (in): 16.54
- Product Width (in): 9.06
- Pump Type: Turbine
- Regulator Included: Yes
- Resistance Ohms Empty: 103
- Resistance Ohms Full: 6
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 5
- Terminal Type: PIN
- UPC: 00072845130587
- Voltage: 12V
- Weight (lbs): 3.19
- Wire Harness Included: No
- Part Description: 1993 Dodge W150 Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge W150 | All Trims | 6 Cyl 3.9L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.2L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
$78.73
Autobest® Fuel Pump Module Assembly for 1993 Dodge W150
PartNumber: F3075AProduct Specifications- Notes: with 30 Gallon Tank;Return less System;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal;Pump Assembly Includes Pressure Regulator
- Average Current Draw(A): 9
- Average Flow Rating(GPH): 47.6
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.433
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Lock Ring Included: No
- Maximum Pump Pressure (PSI): 80
- Minimum Pump Pressure (PSI): 70
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 3/8
- Outlet Type: Quick Connect
- Product Height (in): 6.3
- Product Length (in): 16.81
- Product Width (in): 9.45
- Pump Type: Gerotor
- Regulator Included: Yes
- Resistance Ohms Empty: 103
- Resistance Ohms Full: 6
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 5
- Terminal Type: PIN
- UPC: 00072845130754
- Voltage: 12V
- Weight (lbs): 3.43
- Wire Harness Included: No
- Part Description: 1993 Dodge W150 Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
$106.47
OEM (Genuine) 1993 Dodge W150 CONTRLLER-Fuel Pump & Level
PartNumber: 4762539
Product Specifications- Notes: Gas Engine
- Other Names: Fuel Pump
- Item Weight: 4.00 Pounds
- Part Description: 1993 Dodge W150 CONTRLLER-Fuel Pump & Level
Vehicle Fitment- 1993 Dodge W150 | Base, S | 6 Cyl 3.9 L GAS, 8 Cyl 5.2 L GAS, 8 Cyl 5.9 L GAS
Denso® Fuel Pump and Strainer Set for 1993 Dodge W150
PartNumber: 950-3026Product Specifications- Notes: w/Return Fuel System; OE Replacement Fuel Pump & Strainer Kit;w/Return Fuel System; OE / OES Replacement Fuel Pump & Strainer Kit
- Fuel Pump Type: Electrical
- Gaskets Included: Yes
- Internet Product Code (IPC): D49DD8F1CA1
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 950-3026
- MFG Name: DENSO
- Package Contents: Fuel Pump Kit
- Pump Placement: In Tank
- Supplier Company Name: DENSO
- UPC: 042511170827
- Part Description: 1993 Dodge W150 Fuel Pump and Strainer Set
Vehicle Fitment- 1993 Dodge W150 | All Trims | 6 Cyl 3.9L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.2L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
Hella® Fuel Pump for 1993 Dodge W150
PartNumber: H75015141Product Specifications- Notes: Discontinued; 13.5V; 49PSI; 49GPH HI; IN-TANK
- UPC: 760687051107
- Part Description: 1993 Dodge W150 Fuel Pump
Vehicle Fitment- 1993 Dodge W150 | All Trims | 6 Cyl 3.9L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.2L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
OEM (Genuine) 1993 Dodge W150 Fuel Pump
PartNumber: 68047915AAProduct Specifications- Notes: All Models
- Item Dimensions: 7.2 x 4.9 x 5.3 inches
- Item Weight: 1.10 Pounds
- Replaces: 5174673AA, 5012376AB
- Part Description: 1993 Dodge W150 Fuel Pump
Vehicle Fitment- 1993 Dodge W150 | Base, S | 6 Cyl 3.9 L GAS, 8 Cyl 5.2 L GAS, 8 Cyl 5.9 L GAS
Denso® Fuel Pump Module Assembly for 1993 Dodge W150
PartNumber: 953-3068Product Specifications- Notes: w/Return Fuel System; Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): CD099DA483B
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-3068
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511204546
- Part Description: 1993 Dodge W150 Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge W150 | All Trims | 6 Cyl 3.9L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.2L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
Denso® Fuel Pump Module Assembly for 1993 Dodge W150
PartNumber: 953-6004Product Specifications- Notes: w/Return Fuel System - Sell out reorder 953-3068
- Gaskets Included: Yes
- Internet Product Code (IPC): 714129772BF
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- Meets or Exceeds Original Equipment Manufacture Specifications: YES
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-6004
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Seal And Lock Ring Included: NO
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511171190
- Part Description: 1993 Dodge W150 Fuel Pump Module Assembly
Vehicle Fitment- 1993 Dodge W150 | All Trims | 6 Cyl 3.9L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.2L
- 1993 Dodge W150 | All Trims | 8 Cyl 5.9L
