Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 35502 |
Part Description | Hvac Blower Motor Without Wheel |
Cage Wheel Included | w/o Wheel |
Connector Gender | None |
Connector qty | None |
Flanged End | No |
Material | Metal |
Motor Dia. MM | 76.200 |
Motor Diameter | 3.000 |
Motor Length | 4.500 |
Motor Length MM | 114.300 |
Mount Type | OE Mount |
New or Reman | New |
Number of Terminals | Connector Not Included |
O.E. Replacement | Yes |
Rotation | CW/CCW |
Shaft Diameter | 0.3125 |
Shaft Length | 1.3125 |
Shaft Shape | D-Shaped |
Shaft Type | D-Shaped |
Stud Distance | 2.3125 |
Style | Single Shaft |
Terminal Type | 2 Lead Wires |
UPC | 096361355026 |
Vented | Vented |
Voltage | 12 |
Wheel Dia. IN | Yes |
Year Make Model | Trim | Engine |
---|---|---|
1979-1980 American Motors AMX | All Trims | All Engines |
1974 American Motors Ambassador | All Trims | All Engines |
1978-1980 American Motors Concord | All Trims | All Engines |
1980 American Motors Eagle | All Trims | All Engines |
1970-1978 American Motors Gremlin | All Trims | All Engines |
1970-1977 American Motors Hornet | All Trims | All Engines |
1971-1974 American Motors Javelin | All Trims | All Engines |
1974-1978 American Motors Matador | All Trims | All Engines |
1979-1980 American Motors Spirit | All Trims | All Engines |
1965-1971 Chrysler 300 | All Trims | All Engines |
