Vehicle Specific
Check if it fits by entering your vehicle infoBrand | DuraGo |
Part Number | BD8200 |
Part Description | Rear Brake Drum |
Abs Sensor Ring Includes | No |
Bolt Circle Diameter | 114.3mm (4.5") |
Bolt Hole Diameter | 15.6mm (0.61") |
Bolt Hole Quantity | 5 |
Brake Surface Width | 72.1mm (2.84") |
Center Hole Diameter | 62mm (2.44") |
Construction | Composite |
Drum Type | Floating |
Height | 93mm (3.66") |
Maximum Diameter | 281.69mm (11.09") |
Nominal Diameter | 280.2mm (11.03") |
Outside Diameter | 325mm (12.8") |
Type | Plain Cooling Fins |
UPC | 756632109931 |
Year Make Model | Trim | Engine |
---|---|---|
1965-1968 Ford Country Sedan | All Trims | All Engines |
1960-1968 Ford Country Squire | All Trims | All Engines |
1964-1968 Ford Custom | All Trims | All Engines |
1960 Ford Custom 300 | All Trims | All Engines |
1968 Ford Custom 500 | All Trims | All Engines |
1960-1967 Ford Galaxie | All Trims | All Engines |
1968 Ford Galaxie 500 | All Trims | All Engines |
1965-1968 Ford LTD | All Trims | All Engines |
1967-1968 Ford Ranch Wagon | All Trims | All Engines |
1960 Ford Starliner | All Trims | All Engines |
