Vehicle Specific
Check if it fits by entering your vehicle infoBrand | CSF |
Part Number | 3751 |
Part Description | Engine Coolant Radiator |
Bottom Hose Fitting (in) | 1 5/16 Right |
Box Height (in) | 5 1/4 |
Box Length (in) | 30 1/4 |
Box Weight (lbs) | 8 |
Box Width (in) | 20 3/16 |
Core Length | 21 11/16 |
Core Material | Aluminum |
Core Thickness | 5/8 |
Core Width | 15 5/16 |
Cross-flow/ Down-flow | Cross Flow |
Hazardous Material | No |
Inlet Length (in) | 15 13/16 |
Inlet Width (in) | 1 5/8 |
No. Of Rows | 1 |
UPC | 710353037515 |
OE Part Number | 25310-3X500, 25310-3X600 |
Oil Cooler (in) | 10 13/16 (high-efficiency Plate Type) |
Outlet Length(in) | 15 13/16 |
Outlet Width | 1 5/8 |
Radiator Cap Supplied | No |
Tank Material | Plastic |
Tech Note | O.E.M. style Plastic tanks & Aluminum core. |
Top Hose Fitting (in) | 1 3/8 Left |
Year Make Model | Trim | Engine |
---|---|---|
2014-2016 Hyundai Elantra | All Trims | 4 Cyl 1.8L |
2016 Hyundai Elantra | All Trims | 4 Cyl 2.0L |
2016-2017 Hyundai Elantra GT | All Trims | 4 Cyl 2.0L |
2015-2016 Kia Forte | All Trims | 4 Cyl 1.8L |
2015-2018 Kia Forte | All Trims | 4 Cyl 2.0L |
2014-2016 Kia Forte Koup | All Trims | 4 Cyl 2.0L |
2015-2016 Kia Forte5 | All Trims | 4 Cyl 2.0L |
