Vehicle Specific
Check if it fits by entering your vehicle infoBrand | CSF |
Part Number | 3115 |
Part Description | Engine Coolant Radiator |
Bottom Hose Fitting (in) | 1 1/2 Left |
Box Height (in) | 8 1/16 |
Box Length (in) | 35 |
Box Weight (lbs) | 15 |
Box Width (in) | 27 1/2 |
Core Length | 23 7/16 |
Core Material | Aluminum |
Core Thickness | 7/8 |
Core Width | 20 |
Cross-flow/ Down-flow | Cross Flow |
Csf Cap Number | 4539 |
Hazardous Material | No |
Inlet Length (in) | 20 9/16 |
Inlet Width (in) | 2 1/8 |
No. Of Rows | 1 |
UPC | 710353031155 |
OE Part Number | 2262, 52079428 AD, 52079428 AB, CU2262, 2746, 8012262, CU2336 |
Oil Cooler (in) | 12 (high-efficiency Plate Type) |
Outlet Length(in) | 20 9/16 |
Outlet Width | 2 1/8 |
Radiator Cap Supplied | No |
Tank Material | Plastic |
Tech Note | O.E.M. style Plastic tanks & Aluminum core;Manufactured with steel crimp strips to strengthen Radiator by 40% over O.E. |
Top Hose Fitting (in) | 1 1/2 Right |
Year Make Model | Trim | Engine |
---|---|---|
1999-2004 Jeep Grand Cherokee | All Trims | 6 Cyl 4.0L |
