Notes: Engine Family Number 6CRXT0287P70;CARB Executive Order D-193-143;Engine Family Number 6CRXT0226N70;Certification Level : LEV2 LEV; OE Spec; Cutting & Welding Reqd During Installation
Air Tube: No
Catalytic Converter Body Height: 4"
Catalytic Converter Body Length: 13"
Catalytic Converter Body Shape: Round
Catalytic Converter Overall Length: 13"
Catalytic Converter Substrate Material: Ceramic
Catalytic Converter Width: 4"
Catalytic Inlet Diameter: 2.5"
Catalytic Outlet Diameter: 2.5"
Catalytic Style: Spun
Converter Body Material: Stainless Steel
Converter Configuration: Universal Fit
Heat Shield Attached: No
Inlet Attachment: Weld-On
Inlet Orientation: Straight
Inlet Quantity: 1
O2 Sensor Port: No
Outlet Attachment: Weld-On
Outlet Orientation: Straight
Outlet Quantity: 1
UPC: 888563142715
Part Description: 2006 Jeep Grand Cherokee Direct-Fit Catalytic Converter
Notes: Not legal for use in Calif; Illegal for installation in NY on vehicles equipped w/Calif emission systems; This part is available split & must be welded or clamped together, order left & right Assy
Catalytic Converter Body Height: 12"
Catalytic Converter Overall Length: 38"
Catalytic Converter Width: 8"
Converter Configuration: Direct Fit
Inlet Type: 2 Bolt Spin Flange
O2 Sensor Port: Yes
Outlet Type: 2 Bolt Fixed Flange
Packaging Type: Unboxed
Position: Front Passenger Side
Part Description: 2006 Jeep Grand Cherokee Direct Fit Catalytic Converter and Pipe Assembly
Notes: Not legal for use in Calif; Illegal for installation in NY on vehicles equipped w/Calif emission systems; This part is available split & must be welded or clamped together, order left & right Assy
Catalytic Converter Body Height: 11"
Catalytic Converter Overall Length: 26"
Catalytic Converter Width: 16"
Converter Configuration: Direct Fit
Inlet Type: 2 Bolt Spin Flange
O2 Sensor Port: Yes
Outlet Type: Slip Fit
Packaging Type: Unboxed
Position: Front Driver Side
Part Description: 2006 Jeep Grand Cherokee Direct Fit Catalytic Converter
Notes: CARB Executive Order D-193-120;Engine Family Number 6CRXT0226N70;Certification Level : LEV2 LEV; OE Spec; Cutting & Welding Reqd During Installation
Air Tube Adaptable: No
Body Height: 3.75
Body Length: 12
Body Material: Stainless Steel
Body Shape: Oval
Body Type: Clam Shell
Body Width: 6.375
Finish: Stainless Steel
Heat Shield Attached: Yes
Heat Shield Material: Aluminized Steel
Inlet Attachment: Weld-On
Inlet Diameter: 2
Inlet Orientation: Straight
Inlet Quantity: 1
Material: Stainless Steel
Outlet Attachment: Weld-On
Outlet Diameter: 2
Outlet Orientation: Straight
Outlet Quantity: 1
Overall Length: 16
Oxygen Sensor Location: None
Sensor Port Count: 0
Series: California
Substrate Material: Ceramic
Title: California Universal
UPC: 888563010939
Part Description: 2006 Jeep Grand Cherokee Universal Catalytic Converter
Notes: Not legal for use in Calif; Illegal for installation in NY on vehicles equipped w/Calif emission systems; OE system is a welded Assy, left & right Assy Reqd for full replacement.
Catalytic Converter Overall Length: 32"
Converter Configuration: Direct Fit
Inlet Type: 2 Bolt Loose Flange
O2 Sensor Port: Yes
Outlet Type: Slip Fit
Position: Driver Side
UPC: 841809119247
Part Description: 2006 Jeep Grand Cherokee Direct Fit Catalytic Converter and Pipe Assembly
Notes: Not legal for use in Calif; Illegal for installation in NY on vehicles equipped w/Calif emission systems; OE system is a welded Assy, left & right Assy Reqd for full replacement.
Catalytic Converter Overall Length: 37.25"
Converter Configuration: Direct Fit
Inlet Type: 2 Bolt Loose Flange
O2 Sensor Port: Yes
Outlet Type: 2 Bolt Fixed Flange
Position: Passenger Side
UPC: 841809119254
Part Description: 2006 Jeep Grand Cherokee Direct Fit Catalytic Converter and Pipe Assembly
Notes: Not legal for use in Calif; Illegal for installation in NY on vehicles equipped w/Calif emission systems; OE system is a welded Assy, left & right Assy Reqd for full replacement.
Catalytic Converter Overall Length: 32"
Converter Configuration: Direct Fit
Inlet Type: 2 Bolt Loose Flange
O2 Sensor Port: Yes
Outlet Type: Slip Fit
Position: Driver Side
UPC: 841809119278
Part Description: 2006 Jeep Grand Cherokee Direct Fit Catalytic Converter and Pipe Assembly
Notes: Not legal for use in Calif; Illegal for installation in NY on vehicles equipped w/Calif emission systems; OE system is a welded Assy, left & right Assy Reqd for full replacement.
Catalytic Converter Overall Length: 38.25"
Converter Configuration: Direct Fit
Inlet Type: 2 Bolt Loose Flange
O2 Sensor Port: Yes
Outlet Type: 2 Bolt Fixed Flange
Position: Passenger Side
Part Description: 2006 Jeep Grand Cherokee Direct Fit Catalytic Converter and Pipe Assembly
