Notes: 2 Fuel Pumps may be Required - 1 Externally Mounted & 1 Mounted In Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 5
Flow Rating: 28 gph
Fuel Type: Gas
Gasket or Seal Included: No
In Tank or External: External
Inlet Outside Diameter: 0.313''
Inlet Type: Quick Connect
Item Grade: Standard Replacement
Maximum Pressure: 99.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Quick Connect
Pump Type: Electric
Strainer Included: No
System Pressure: 44 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Threaded
UPC: 689604032619
Voltage: 12 VDC
Wiring Harness Included: No
Part Description: 1984 Mercury Capri In Line Electric Fuel Pump
Notes: 2 Fuel Pumps may be Required - 1 Externally Mounted & 1 Mounted In Tank;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Current Draw: 10
Flow Rating: 39 gph
Fuel Type: Gas
Gasket or Seal Included: Yes
In Tank or External: In Tank
Inlet Type: Strainer
Item Grade: Standard Replacement
Maximum Pressure: 9.0 PSI
Outlet Outside Diameter: 0.313''
Outlet Type: Hose
Pump Type: Electric
Strainer Included: No
System Pressure: 6 psi
Terminal Gender: Male
Terminal Quantity: 2
Terminal Type: Pin
UPC: 689604033951
Voltage: 14 VDC
Wiring Harness Included: No
Part Description: 1984 Mercury Capri In Tank Electric Fuel Pump
Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
Item Grade: Standard Replacement
Micron Rating: 60
Strainer Material: Saran
UPC: 689604220917
Part Description: 1984 Mercury Capri Fuel Pump Strainer
Notes: For 2" Gauge Hole;For 2" Gauge Hole; For 11.3 or 13 Gallons Tank; Lock Ring (Fuel Level Sender); Lock Ring (Air Vent); Lock Ring (Fuel Pump Assy); (Incls O-Ring)
Inside Diameter: 2-1/8
Material: Steel / Polymer
Outside Diameter: 2-5/8
UPC: 671607110029
Part Description: 1984 Mercury Capri Fuel Tank Lock Ring
