Replacement and OEM Parts for 2009 Cadillac CTS Fuel Pump

2009 Cadillac CTS Fuel Pump

My Vehicle Change Vehicle
2009 Cadillac CTS
Change Vehicle
Vehicle Options
We need more information about your vehicle to make a correct determination of fitment
< Back to View All
Fuel Systems
  • Department
  • Brands
  • Prices

10 Products found

Show Item:
  • 30
  • 60
  • 90
Sort by:
Recommended
Filter
Sort
View by
  • OEM 2009 Cadillac CTS Fuel Pump Diagram - 12658552
    View Related Parts

    OEM (Genuine) 2009 Cadillac CTS Fuel Pump

    PartNumber: 12658552
    OEM 2009 Cadillac CTS Fuel Pump - 12658552
    Product Specifications
    • Notes: Cts; Front
    • Item Dimensions: 12.4 x 12.4 x 8.3 inches
    • Item Weight: 4.30 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 12614934, 12676667, 12634492, 12647344, 12639260, 12626234
    • Part Description: 2009 Cadillac CTS Fuel Pump
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | Base, V | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
    $299.99 MSRP: $525.16
    You Save: $225.17 (43%)
  • Delphi Fuel Pump Module Assembly for 2009 Cadillac CTS - FG1301

    Delphi® Fuel Pump Module Assembly for 2009 Cadillac CTS

    PartNumber: FG1301
    Product Specifications
    • Notes: Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
    • Current Draw: 9
    • Flow Rating: 55 gph
    • Fuel Level Sender Assembly Included: No
    • Fuel Type: Gas
    • Gasket or Seal Included: Yes
    • In Tank or External: In Tank
    • Inlet Type: Strainer
    • Internal or External Strainer: Internal
    • Item Grade: Standard Replacement
    • Maximum Pressure: 109.0 PSI
    • Outlet Outside Diameter: 0.375''
    • Outlet Quantity: 1
    • Outlet Type: Quick Connect
    • Pump Type: Electric
    • Regulator Included: No
    • Strainer Included: Yes
    • System Pressure: 58 psi
    • Terminal Gender: Male
    • Terminal Quantity: 4
    • Terminal Type: Blade
    • UPC: 689604232675
    • Vapor Pressure Sensor: No
    • Voltage: 12.0 VDC
    • Part Description: 2009 Cadillac CTS Fuel Pump Module Assembly
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | All Trims | 6 Cyl 3.6L
    $236.74
  • Delphi Mechanical Fuel Pump for 2009 Cadillac CTS - HM10010

    Delphi® Mechanical Fuel Pump for 2009 Cadillac CTS

    PartNumber: HM10010
    Product Specifications
    • Drive Shaft Included: No
    • Fuel Type: Gas
    • Gasket or Seal Included: Yes
    • Housing Color: Silver
    • Housing Material: Metal
    • In Tank or External: External
    • Inlet Fitting Thread Size: M14-1.5mm
    • Inlet Type: Threaded
    • Item Grade: Standard Replacement
    • Mounting Hardware Included: No
    • Outlet Fitting Thread Size: M14-1.5mm
    • Outlet Quantity: 2
    • Outlet Type: Threaded
    • Pump Type: Mechanical
    • Terminal Gender: Male
    • Terminal Quantity: 2
    • Terminal Type: Blade
    • UPC: 689604264768
    • Wiring Harness Included: No
    • Part Description: 2009 Cadillac CTS Mechanical Fuel Pump
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | All Trims | 6 Cyl 3.6L
    $204.68
  • OEM 2009 Cadillac CTS Fuel Pump Diagram - 19208373
    View Related Parts

    OEM (Genuine) 2009 Cadillac CTS Fuel Pump

    PartNumber: 19208373
    OEM 2009 Cadillac CTS Fuel Pump - 19208373
    Product Specifications
    • Other Names: Fuel Pump
    • Item Dimensions: 17.0 x 14.5 x 9.9 inches
    • Item Weight: 2.70 Pounds
    • Replaced by: 19417959
    • Part Description: 2009 Cadillac CTS Fuel Pump
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | Base, V | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
  • OEM 2009 Cadillac CTS Fuel Pump Diagram - 19417959
    View Related Parts

    OEM (Genuine) 2009 Cadillac CTS Fuel Pump

    PartNumber: 19417959
    OEM 2009 Cadillac CTS Fuel Pump - 19417959
    Product Specifications
    • Other Names: Fuel Pump, Fuel Pump Assembly
    • Item Dimensions: 17.1 x 13.8 x 10.4 inches
    • Item Weight: 2.70 Pounds
    • Fitment Type: Direct Replacement
    • Replaces: 19208373, 19168842, 19180435
    • Part Description: 2009 Cadillac CTS Fuel Pump
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | Base, V | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
  • Airtex Direct Injection High Pressure Fuel Pump for 2009 Cadillac CTS - D30009

    Airtex® Direct Injection High Pressure Fuel Pump for 2009 Cadillac CTS

    PartNumber: D30009
    Product Specifications
    • Gasket or Seal Included: Yes
    • Inlet Outside Diameter: 13.8
    • Inlet Type: Threaded
    • Internal or External: External
    • Mounting Hardware Included: No
    • Muffler Outlet Diameter (in): 13.8
    • Outlet Type: Threaded
    • Pump Type: Mechanical
    • UPC: 889464031993
    • Part Description: 2009 Cadillac CTS Direct Injection High Pressure Fuel Pump
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | All Trims | 6 Cyl 3.6L
  • Autobest Fuel Pump Module Assembly for 2009 Cadillac CTS - F2709A

    Autobest® Fuel Pump Module Assembly for 2009 Cadillac CTS

    PartNumber: F2709A
    Product Specifications
    • Notes: Includes Fuel Pump, Fuel Pressure Regulator, Fuel Reservoir, Fuel Strainer and Tank Seal
    • Average Current Draw(A): 7.9
    • Average Flow Rating(GPH): 31.4
    • Connector Gender: Male
    • Connector Quantity: 1
    • Connector Shape: Rectangle
    • Country of Orign: China
    • Fuel Filter Included: Yes
    • Fuel Sending Unit Included: Yes
    • Fuel Tank Pressure Sensor Included: No
    • Gasket or Seal Included: Yes
    • Gasket Or Seal Material: NBR
    • Grade Type: Performance
    • Housing Material: POM
    • In Tank or External: In Tank
    • Inlet Size: 11.8
    • Inlet Type: Quick Connect
    • Installation Warnings: No
    • Internal Or External Strainer: Internal
    • Lock Ring Included: No
    • Maximum Pump Pressure (PSI): 60
    • Minimum Pump Pressure (PSI): 60
    • Mounting Hardware Included: No
    • Negative Ground: Yes
    • Outlet Quantity: 1
    • Outlet Size: 3/8
    • Outlet Type: Quick Connect
    • Product Height (in): 8.5
    • Product Length (in): 9.29
    • Product Width (in): 9.02
    • Pump Type: Turbine
    • Regulator Included: No
    • Resistance Ohms Empty: 250
    • Resistance Ohms Full: 40
    • Strainer Included: Yes
    • Terminal Gender: Male
    • Terminal Quantity: 4
    • Terminal Type: PIN
    • UPC: 00072845127099
    • Voltage: 12V
    • Weight (lbs): 2.79
    • Wire Harness Included: No
    • Part Description: 2009 Cadillac CTS Fuel Pump Module Assembly
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | All Trims | 6 Cyl 3.6L
  • Airtex Fuel Pump Module Assembly for 2009 Cadillac CTS - E3787M

    Airtex® Fuel Pump Module Assembly for 2009 Cadillac CTS

    PartNumber: E3787M
    Product Specifications
    • Notes: w/o Fuel Level Sensor; Incls Fuel Pump, Fuel Pressure Reg, Fuel Reservoir, Fuel Strainer & Tank Seal
    • Gasket Included: Y
    • Inlet Count: 1
    • Inlet Type: STRAINER
    • Item Grade: STANDARD REPLACEMENT
    • Maximum Free Flow Rate (gph): 90
    • Maximum Pressure Rate (psi): 130
    • Minimum Free Flow Rate (gph): 80
    • Minimum Pressure Rate (psi): 85
    • Outlet Count: 1
    • Outlet Size: 3/8"
    • Outlet Type: QUICK CONNECT
    • Package Contents: PUMP & KIT
    • Package Quantity: 1
    • UPC: 080044042754
    • Part Description: 2009 Cadillac CTS Fuel Pump Module Assembly
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | V | 8 Cyl 6.2L
  • Airtex Fuel Pump Module Assembly for 2009 Cadillac CTS - E3798M

    Airtex® Fuel Pump Module Assembly for 2009 Cadillac CTS

    PartNumber: E3798M
    Product Specifications
    • Gasket or Seal Included: Yes
    • Inlet Count: 1
    • Inlet Type: STRAINER
    • Internal or External: Internal
    • Item Grade: STANDARD REPLACEMENT
    • Maximum Free Flow Rate (gph): 65
    • Maximum Pressure (psi): 60
    • Minimum Free Flow Rate (gph): 55
    • Minimum Pressure (psi): 60.0
    • Outlet Count: 1
    • Outlet Size: 3/8
    • Outlet Type: QUICK CONNECT
    • Package Contents: PUMP & KIT
    • Package Quantity: 1
    • Pump Type: Electrical
    • UPC: 080044037996
    • Voltage [V]: 12V
    • Wiring Harness Included: No
    • Part Description: 2009 Cadillac CTS Fuel Pump Module Assembly
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | All Trims | 6 Cyl 3.6L
  • OEM 2009 Cadillac CTS Fuel Tank Fuel Pump Module Kit (W/O Fuel Level Sensor) Diagram - 19207950
    View Related Parts

    OEM (Genuine) 2009 Cadillac CTS Fuel Tank Fuel Pump Module Kit (W/O Fuel Level Sensor)

    PartNumber: 19207950
    OEM 2009 Cadillac CTS Fuel Tank Fuel Pump Module Kit (W/O Fuel Level Sensor) - 19207950
    Product Specifications
    • Notes: Cts-V
    • Other Names: Fuel Pump, Fuel Pump Assembly
    • Item Dimensions: 14.7 x 12.5 x 12.4 inches
    • Item Weight: 2.20 Pounds
    • Fitment Type: Direct Replacement
    • Part Description: 2009 Cadillac CTS Fuel Tank Fuel Pump Module Kit (W/O Fuel Level Sensor)
    More Info
    Vehicle Fitment
    • 2009 Cadillac CTS | V | 8 Cyl 6.2 L GAS
