Replacement and OEM Parts for 2007 Cadillac Escalade ESV Brake Pad Set

2007 Cadillac Escalade ESV Brake Pad Set

My Vehicle Change Vehicle
2007 Cadillac Escalade ESV
Change Vehicle
Vehicle Options
We need more information about your vehicle to make a correct determination of fitment
< Back to View All
Brake Pads, Discs & Calipers
  • Department
  • Friction Material Composition
  • Material
  • Series
  • Brands
  • Prices

37 Products found

10 Q&A for Brake Pad Set Repair
Show Item:
  • 30
  • 60
  • 90
Sort by:
Recommended
Filter
Sort
View by
1-30 of 37 Results
< Previous
12
Next >

FAQ for Brake Pad Set Repair

Q: How do you install the rear disc brake pads (2500 series)?
A:
You need to install new brake pad retaining springs to the caliper bracket, and the brake pads to the caliper bracket. Install the caliper to the caliper bracket, the brake caliper bolts, and the tire and wheel assembly. With the engine off, gradually apply the brake pedal to approximately 2/3 of its travel distance. Then you can slowly release the brake pedal and wait 15 seconds, then repeat steps 7-8 until a firm pedal is obtained, to properly seat the brake caliper pistons and brake pads and then fill the master cylinder reservoir to the proper level with clean brake fluid and burnish the pads and rotors.
By Bob
GM Specialist
01/11/2022
Q: How to compress the brake caliper pistons?
A:
You need to install 2 large C-clamps over the top of the caliper housing and against the back of the outboard brake pad, slowly tighten the C-clamps until the caliper pistons a pushed completely into the caliper bores and remove the C-clamps from the caliper.
By Bob
GM Specialist
01/11/2022
Q: What is the recommended torque for the brake caliper guide pin?
A:
The recommended torque is 108 N.m (80 Ib in).
By Bob
GM Specialist
01/11/2022
Q: What is the removal procedure for the rear disc brake pads (1500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the fluid level is midway between the maximum-full point and the minimum allowable level, no fluid needs to be removed from the reservoir before proceeding. If the fluid level is higher than midway between the maximum-full point and the minimum allowable level, remove fluid to the midway point before proceeding. Then you can raise and support the vehicle, remove the tire and wheel assembly, compress the brake caliper piston, remove the guide pin bolt from the brake caliper and rotate the brake caliper upward until it stops on the caliper mounting bracket and supports the caliper with heavy mechanics wire or equivalent.
By Bob
GM Specialist
01/11/2022
Q: How do you remove the front disc brake pads (1500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the fluid level is midway between the maximum-full point and the minimum allowable level, no fluid needs to be removed from the reservoir before proceeding. If the fluid level is higher than midway between the maximum-full point and the minimum allowable level, remove fluid to the midway point before proceeding. Then you can raise and support the vehicle, remove the tire and wheel assembly, compress the brake caliper pistons, remove the lower brake caliper guide pin bolt and rotate the brake caliper upward until it rests on the brake caliper mounting bracket and support with heavy mechanics wire or equivalent.
By Bob
GM Specialist
01/11/2022
Q: What is the proper way to install the rear disc brake pads (1500 series)?
A:
The proper way is to install the retaining springs on the caliper mounting bracket and the brake pads, remove the mechanics wire, rotate the brake caliper into position on the mounting bracket, and install new caliper guide pin bolts and the tire and wheel assembly. With the engine off, gradually apply the brake pedal to approximately 2/3 of its travel distance. Then you can slowly release the brake pedal, wait 15 seconds, then repeat steps 8-9 until a firm pedal is obtained, to properly seat the brake caliper pistons and brake pads, fill the brake master cylinder reservoir to the proper level with clean brake fluid and burnish the brake pads and rotors.
By Bob
GM Specialist
01/11/2022
Q: What is the brake pad and rotor burnishing procedure?
A:
You need to select a smooth road with little or no traffic, accelerate the vehicle to 48 km/h (30 mph), apply the brakes to bring the vehicle to a stop, and repeat steps 2 and 3 until approximately 20 stops have been completed and allow sufficient cooling periods between stops to properly burnish the brake pads and rotors.
By Bob
GM Specialist
01/11/2022
Q: What should I avoid doing when accelerating the vehicle to 48 km/h (30 mph)?
A:
You should avoid overheating the brakes while performing this step.
By Bob
GM Specialist
01/11/2022
Q: How do you install the front disc brake pads (1500 series)?
A:
You need to install the shims to the mounting bracket, rotate the brake caliper into the proper position on the mounting bracket, and install the tire and wheel assembly. With the engine off, gradually apply the brake pedal to approximately 2/3 of its travel distance. Then you can slowly release the brake pedal, wait 15 seconds, then repeat steps 7-8 until a firm pedal is obtained to properly seat the brake caliper pistons and pads, fill the brake master cylinder reservoir to the proper level with clean brake fluid and burnish the pads and rotors.
By Bob
GM Specialist
01/11/2022
Q: How do you remove the rear disc brake pads (2500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the fluid level is midway between the maximum-full point, and the minimum allowable level, no fluid needs to be removed from the reservoir before proceeding. If the fluid level is higher than midway between the maximum-full point, and the minimum allowable level, remove fluid to the midway point before proceeding. Next, you can raise and support the vehicle, remove the tire and wheel assembly and compress the brake caliper pistons. Then you can remove the brake caliper guide pin bolts, the caliper from the caliper bracket and support with heavy mechanics wire or equivalent, the brake pads from the caliper bracket, remove and discard the brake pad retaining springs and inspect the brake caliper.
By Bob
GM Specialist
01/11/2022
See more FAQs (5)

FAQ for Other Repair Info

Q: How do you remove the front brake caliper (2500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the brake fluid level is midway between the maximum-full point and the minimum allowable level, no brake fluid needs to be removed from the reservoir before proceeding. If the brake fluid level is higher than midway between the maximum-full point and the minimum allowable level, remove the brake fluid to the midway point before proceeding. Next, you can raise and support the vehicle, remove the tire and wheel assembly, compress the Brake Caliper pistons and clean all dirt and debris from the brake caliper and fittings. Then you can remove the brake hose from the brake caliper, and discard the 2 copper brake hose gaskets, the brake caliper guide pin bolts from the brake caliper, and the brake caliper from the caliper mounting bracket.
Q: What should you do before installing the caliper bracket mounting bolts?
A:
You need to remove all traces of the original adhesive patch, clean the threads of the bolts with brake parts cleaner or equivalent and allow them to dry, and apply Threadlocker GM P/N 12345493 (Canadian P/N 10953488) to the threads of the bolts.
