Replacement and OEM Parts for 2007 Cadillac Escalade ESV Brake Caliper

2007 Cadillac Escalade ESV Brake Caliper

My Vehicle Change Vehicle
2007 Cadillac Escalade ESV
Change Vehicle
Vehicle Options
We need more information about your vehicle to make a correct determination of fitment
< Back to View All
Brake Pads, Discs & Calipers
  • Department
  • Installation Hardware Included
  • Pads Included
  • Series
  • Brands
  • Prices

22 Products found

21 Q&A for Brake Caliper Repair
Show Item:
  • 30
  • 60
  • 90
Sort by:
Recommended
Filter
Sort
View by

FAQ for Brake Caliper Repair

Q: Under what condition should you replace the pistons or the caliper?
A:
You should replace the pistons or the caliper if any of the following conditions exist: scoring in the caliper bores, corrosion in the caliper bores, pitting in the caliper bores, and damage to the pistons (phenolic).
By Bob
GM Specialist
29/10/2022
Q: How do you install the rear brake caliper bracket (2500 series)?
A:
You need to install the retaining springs to the caliper bracket, the brake pads, the caliper to the caliper bracket, the brake caliper guide pin bolts to the caliper bracket, and the caliper and caliper bracket as an assembly. Next, you can perform the following procedure before installing the caliper bracket bolts, install the brake caliper bracket mounting bolts, tighten the brake caliper guide pin bolts and install the tire and wheel assembly. With the engine OFF, gradually apply the brake pedal to approximately 2/3 of its travel distance. Then you can slowly release the brake pedal, wait 15 seconds, then repeat steps 10-11 until a firm pedal is obtained to properly seat the brake caliper pistons and brake pads and fill the master cylinder reservoir to the proper level with clean brake fluid, if necessary.
By Bob
GM Specialist
29/10/2022
Q: What should I avoid doing when removing the caliper from the caliper bracket?
A:
You can not reuse the old brake pad retaining springs with new brake pads and replace them with new only.
By Bob
GM Specialist
29/10/2022
Q: How do you remove the front brake caliper bracket (1500 series)?
A:
You need to raise and support the vehicle, and remove the tire and wheel assembly, the caliper, and support with heavy mechanics wire or equivalent, the brake pads, and springs, the brake caliper bracket mounting bolts, and the brake caliper bracket.
By Bob
GM Specialist
29/10/2022
Q: How do you remove the rear brake caliper (1500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the fluid level is midway between the maximum-full point and the minimum allowable level, no fluid needs to be removed from the reservoir before proceeding. If the fluid level is higher than midway between the maximum-full point and the minimum allowable level, remove fluid to the midway point before proceeding. Next, you can raise and support the vehicle, remove the tire and wheel assembly, clean all dirt and foreign material from the brake hose fitting, compress the caliper piston, remove the brake hose to the caliper bolt, position the brake hose to the side and remove the brake caliper from the mounting bracket.
By Bob
GM Specialist
29/10/2022
Q: How do you remove the rear brake caliper bracket (2500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the fluid level is midway between the maximum-full point, and the minimum allowable level, no fluid needs to be removed from the reservoir before proceeding. If the fluid level is higher than midway between the maximum-full point, and the minimum allowable level, remove fluid to the midway point before proceeding. Next, you can raise and support the vehicle, remove the tire and wheel assembly, compress the brake caliper pistons and loosen them, but do not remove the rear brake caliper guide pin bolts. Then you can remove the brake caliper bracket mounting bolts, the caliper bracket and brake caliper as an assembly, the caliper guide pin bolts from the caliper bracket, the brake pads from the caliper bracket, and the retaining springs.
By Bob
GM Specialist
29/10/2022
Q: What is the recommended torque for the bleeder valve?
A:
The recommended torque is 12 N.m (106 Ib in).
By Bob
GM Specialist
29/10/2022
Q: How do you install the rear brake caliper (2500 series)?
A:
You need to install the brake caliper to the mounting bracket and the brake caliper guide pin bolts, remove the cap or plug from the brake hose to the caliper fitting, assemble the 2 new copper brake hose gaskets to the brake hose bolt and brake hose, and install the brake hose to caliper bolt. Then you can bleed the hydraulic brake system, install the tire and wheel assembly and fill the master cylinder reservoir to the proper level with clean brake fluid, if necessary.
By Bob
GM Specialist
29/10/2022
Q: How do you install the front brake caliper (1500 series)?
A:
You need to install the caliper to the caliper bracket and the brake caliper bolts, remove the cap or plug from the brake hose fitting end, install the brake hose to the caliper bolt, bleed the hydraulic brake system, install the tire and wheel assembly and fill the master cylinder reservoir to the proper level with clean brake fluid, if necessary.
By Bob
GM Specialist
29/10/2022
Q: How do you remove the rear brake caliper (2500 series)?
A:
You need to inspect the fluid level in the brake master cylinder reservoir. If the brake fluid level is midway between the maximum-full point and the minimum allowable level, no brake fluid needs to be removed from the reservoir before proceeding. If the brake fluid level is higher than midway between the maximum-full point and the minimum allowable level, remove the brake fluid to the midway point before proceeding. Next, you can raise and support the vehicle, remove the tire and wheel assembly, compress the brake caliper pistons and clean all dirt and debris from the brake caliper and fittings. Then you can remove the brake hose to the caliper bolt, the brake hose from the caliper, the brake caliper guide pin bolts from the brake caliper, and the brake caliper from the mounting bracket.
By Bob
GM Specialist
29/10/2022
See more FAQs (16)

FAQ for Other Repair Info

Q: What should you do before installing the caliper bracket mounting bolts?
A:
You need to remove all traces of the original adhesive patch, clean the threads of the bolts with brake parts cleaner or equivalent and allow them to dry, and apply Threadlocker GM P/N 12345493 (Canadian P/N 10953488) to the threads of the bolts.
Q: How do you install the rear disc brake pads (2500 series)?
A:
You need to install new brake pad retaining springs to the caliper bracket, and the brake pads to the caliper bracket. Install the caliper to the caliper bracket, the brake caliper bolts, and the tire and wheel assembly. With the engine off, gradually apply the brake pedal to approximately 2/3 of its travel distance. Then you can slowly release the brake pedal and wait 15 seconds, then repeat steps 7-8 until a firm pedal is obtained, to properly seat the brake caliper pistons and brake pads and then fill the master cylinder reservoir to the proper level with clean brake fluid and burnish the pads and rotors.
