Name: Dorman Hvac Heater Hose Assembly 626-113 for 2002 Chevrolet Monte Carlo
Brand: Dorman
SKU: Dorman 626-113
Price: 71.10 USD
Availability: InStock

Help Center

My Vehicle Change Vehicle

2002 Chevrolet Monte Carlo

Change Vehicle

Vehicle Options

15 Products found

Show Item:

Sort by:

Recommended

Filter

Sort

View by

Dorman® Hvac Heater Hose Assembly for 2002 Chevrolet Monte Carlo
PartNumber: 626-113
Product Specifications
Notes: Thermostat Bypass Pipe; To Front Cover
Color: Black
Construction: Rubber
Hardware: Use Existing Hardware
OE Part Number: 24507875
UPC: 019495356004
Part Description: 2002 Chevrolet Monte Carlo Hvac Heater Hose Assembly
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$71.10
Gates® Safety Stripe Hvac Heater Hose for 2002 Chevrolet Monte Carlo
PartNumber: 28409
Product Specifications
Notes: Cut to Length, 20"
Centerline Length: 50 ft
End 1 Inside Diameter: 10 mm
End 2 Inside Diameter: .375 in
Material: EPDM
OE Part Number: 8899
UPC: 072053081183
Weight Per Length: 8.25 lbs./Carton
Working Pressure: 60 PSI
Part Description: 2002 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
$44.06
Dayco® Small Id Hvac Heater Hose for 2002 Chevrolet Monte Carlo
PartNumber: 87880
Product Specifications
Notes: Bottom Hose; Cut to Fit
Color: Black
Contains Heat Shield: N
Contains Protective Sleeve: N
End 1 Inside Diameter: 5/8
End 1 Outside Diameter: 15/16
End 2 Inside Diameter: 3/4
End 2 Outside Diameter: 1 1/16
Hose Type: Dual I.D. Hose
Material: EPDM
SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
Trunk Height: 14
UPC: 036687683519
Part Description: 2002 Chevrolet Monte Carlo Small Id Hvac Heater Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$14.30
Dorman® Hvac Heater Hose Assembly for 2002 Chevrolet Monte Carlo
PartNumber: 626-525
Product Specifications
Notes: Heater Hose Inlet Tube
Color: Black/Coated
Coolant Hose Heat Shield Included: No Heat Shield Required
Coolant Hose Length: 10"
Coolant Hose Material: Steel
Coolant Hose Protective Sleeve Included: No Protective Sleeve Required
Coolant Hose Type: Single I.D. (Inside Diameter)
End 1 Attachment Type: Flange
End 2 Attachment Type: Flared
Hose End (1) Inside Diameter (In): 0.52"
Hose End (1) Outside Diameter (In): 0.74"
Hose End (2) Inside Diameter (In): 0.55"
Hose End (2) Outside Diameter (In): 0.64"
Maximum Working Pressure (psi): 100
OE Part Number: 12568743
Package Contents: Heater Hose Assembly
SAE Standards: Not Applicable
Thermostatically Controlled: No
UPC: 037495332422
With Clamps: No
Part Description: 2002 Chevrolet Monte Carlo Hvac Heater Hose Assembly
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$42.83
Gates® Safety Stripe Hvac Heater Hose for 2002 Chevrolet Monte Carlo
PartNumber: 28408
Product Specifications
Notes: Cut to Length, 3"
Centerline Length (in): 600"
Inside Diameter 1 (in): 0.3125"
OE Part Number: 49692
UPC: 072053133226
Weight Per Length: 7.25 lbs./Carton
Working Pressure (psi): 60
Part Description: 2002 Chevrolet Monte Carlo Safety Stripe Hvac Heater Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$36.97
Dayco® Small Id Hvac Heater Hose for 2002 Chevrolet Monte Carlo
PartNumber: 86123
Product Specifications
Notes: Top Hose
Color: Black
Contains Heat Shield: N
Contains Protective Sleeve: N
End 1 Inside Diameter: 5/8
End 2 Inside Diameter: 5/8
Hose Type: Single I.D. Hose
Material: EPDM
SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
Trunk Height: 16
UPC: 038244356034
Part Description: 2002 Chevrolet Monte Carlo Small Id Hvac Heater Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$11.31
Dorman® Hvac Heater Hose Assembly for 2002 Chevrolet Monte Carlo
PartNumber: 626-107
Product Specifications
Notes: Thermostat Bypass Pipe; Part of the Lower Intake
Color: Black
Construction: Rubber
Hardware: Use Existing Hardware
OE Part Number: 12590279
UPC: 019495291053
Part Description: 2002 Chevrolet Monte Carlo Hvac Heater Hose Assembly
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$28.03
Gates® Hvac Heater Molded Hose for 2002 Chevrolet Monte Carlo
PartNumber: 19210
Product Specifications
Centerline Length (in): 15"
Inside Diameter 1 (in): 0.64"
Inside Diameter 2 (in): 0.75"
Number of Branches: 0
UPC: 072053559446
Part Description: 2002 Chevrolet Monte Carlo Hvac Heater Molded Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$22.77
Dayco® Small Id Hvac Heater Hose for 2002 Chevrolet Monte Carlo
PartNumber: 87606
Product Specifications
Notes: Bottom Hose
Color: Black
Contains Heat Shield: N
Contains Protective Sleeve: N
End 1 Inside Diameter: 5/8
End 2 Inside Diameter: 3/4
Hose Type: Dual I.D. Hose
Material: EPDM
SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
Trunk Height: 25
UPC: 038244597932
Part Description: 2002 Chevrolet Monte Carlo Small Id Hvac Heater Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
$12.60
Gates® Upper Hvac Heater Molded Hose for 2002 Chevrolet Monte Carlo
PartNumber: 19120
Product Specifications
Centerline Length (in): 24.9"
Inside Diameter 1 (in): 0.59"
Number of Branches: 0
UPC: 072053467086
Part Description: 2002 Chevrolet Monte Carlo Upper Hvac Heater Molded Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
$14.32
Gates® Engine Coolant Molded Bypass Hose for 2002 Chevrolet Monte Carlo
PartNumber: 18020
Product Specifications
Notes: Cut to fit
Centerline Length (in): 9.6"
Inside Diameter 1 (in): 0.31"
Number of Branches: 0
OE Part Number: 42569
UPC: 072053178029
Part Description: 2002 Chevrolet Monte Carlo Engine Coolant Molded Bypass Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$12.47
Gates® Engine Coolant Molded Bypass Hose for 2002 Chevrolet Monte Carlo
PartNumber: 19026
Product Specifications
Branch Quantity: 0
Centerline Length (in): 6
Centerline Length (mm): 152
End 1 Inside Diameter: 0.59 in
End 2 Inside Diameter: 0.59 in
Material: EPDM
Molded: Yes
Number of Quick Connect Fittings: 0
OE Part Number: 2465
UPC: 072053199383
Part Description: 2002 Chevrolet Monte Carlo Engine Coolant Molded Bypass Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$4.95
Dayco® Small Id Hvac Heater Hose for 2002 Chevrolet Monte Carlo
PartNumber: 86800
Product Specifications
Notes: 90 Degree Hose
Color: Black
Contains Heat Shield: N
Contains Protective Sleeve: N
End 1 Inside Diameter: 5/16
End 2 Inside Diameter: 5/16
Hose Type: Single I.D. Hose
Material: EPDM
SAE Specification: SAE J20R3 Class D-1, SAE J1684 Type EC
Trunk Height: 8 1/4
UPC: 038244597512
Part Description: 2002 Chevrolet Monte Carlo Small Id Hvac Heater Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$11.06
Gates® Lower Hvac Heater Molded Hose for 2002 Chevrolet Monte Carlo
PartNumber: 19121
Product Specifications
Centerline Length (in): 22.6"
Inside Diameter 1 (in): 0.62"
Inside Diameter 2 (in): 0.72"
Number of Branches: 0
UPC: 072053467109
Part Description: 2002 Chevrolet Monte Carlo Lower Hvac Heater Molded Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.8L
$14.73
Gates® Hvac Heater Molded Hose for 2002 Chevrolet Monte Carlo
PartNumber: 19211
Product Specifications
Centerline Length (in): 19.3"
Inside Diameter 1 (in): 0.64"
Number of Branches: 0
UPC: 072053553963
Part Description: 2002 Chevrolet Monte Carlo Hvac Heater Molded Hose
More Info
Vehicle Fitment
2002 Chevrolet Monte Carlo | All Trims | 6 Cyl 3.4L
$12.75
