Dorman® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: 2630303Product Specifications- Notes: w/Harness Code (SFU, SGJ)
- OE Part Number: 25178731
- UPC: 747214016372
- Part Description: Fuel Pump Module Assembly
$118.54
Delphi® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: FG0287Product Specifications- Notes: RPO Code NE2;with Plastic Tank;with 18 Gallon Tank;Updated design w/Check Valve. Can be used to replace fuel pump modules built w/or w/o check valve; To be used only when failed fuel module cover contains a 3-pin black pressure sensor; Original OE design had a 2x2 connector, OE design upgraded to a 1x4 connector; A 1x4 splice kit included for vehicles w/2x2 connector; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 9
- Flow Rating: 24 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: External
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604082485
- Vapor Pressure Sensor: Yes
- Voltage: 12.0 VDC
- Part Description: Fuel Pump Module Assembly
$212.41
TYC® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: 150019-AProduct Specifications- Notes: Plastic Fuel Tank
- Accessories Included: yes
- Connector Pins Qty On Main Connector: 4PINS
- Fuel Level Sensor Resitance Range: 39-250
- Fuel Tube Connection Type: Quick Connect
- GPH (Gallons Per Hour Flow): 48.6-57.7
- Maximum Air Pressure: 79.75-123.25
- OE Part Number: 15207041
- Strainer Included: yes
- UPC: 762405824154
- Part Description: Fuel Pump Module Assembly
$84.39
Autobest® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: F2964AProduct Specifications- Notes: with Steel Tank;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer, Upgraded Wiring Harness and Tank Seal
- Average Current Draw(A): 8
- Average Flow Rating(GPH): 33
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Fuel Type: Turbine
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Internal or External: Internal
- Lock Ring Included: No
- Maximum Free Flow (GPH): 55.5
- Maximum Pump Pressure (PSI): 145
- Minimum Free Flow (GPH): 45
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 3/8
- Outlet Type: Quick Connect
- Product Height (in): 7.87
- Product Length (in): 13.66
- Product Width (in): 8.94
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129642
- Voltage: 12V
- Weight (lbs): 2.25
- Wire Harness Included: Yes
- Part Description: Fuel Pump Module Assembly
$64.37
Delphi® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: FG0071Product Specifications- Notes: without 18 Gallon Tank;Except RFI Filter Stamped GAV;with Steel Tank;Original OE design had a 2x2 connector, OE design upgraded to a 1x4 connector; A 1x4 splice kit included for vehicles w/2x2 connector; Confirm the cover of the part you are replacing has a black electrical pressure sensor on cover; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604060087
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: Fuel Pump Module Assembly
$205.38
Airtex® In-Tank Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: E3992MProduct Specifications- Notes: Includes Seal;with Harness;with 18 Gallon Tank;Turbine Pump Technology
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 55
- Maximum Pressure Rate (psi): 90
- Minimum Free Flow Rate (gph): 45
- Minimum Pressure Rate (psi): 70
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect, Return Line
- Package Contents: Pump & Kit
- Package Quantity: 1
- UPC: 080044516569
- Warranty: Lifetime Limited Warranty
- Part Description: In-Tank Fuel Pump Module Assembly
$105.63
Autobest® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: F2903AProduct Specifications- Notes: w/Plastic Tank;Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer, Upgraded Wiring Harness and Tank Seal
- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 41
- Connector Gender: Male
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: Yes
- Fuel Type: Turbine
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: NBR
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 5/16
- Inlet Type: Quick Connect
- Installation Warnings: No
- Internal or External: Internal
- Lock Ring Included: No
- Maximum Free Flow (GPH): 71.5
- Maximum Pump Pressure (PSI): 145
- Minimum Free Flow (GPH): 60.7
- Minimum Pump Pressure (PSI): 87
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 3/8
- Outlet Type: Quick Connect
- Product Height (in): 8.66
- Product Length (in): 12.6
- Product Width (in): 8.66
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 40
- Resistance Ohms Full: 250
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: PIN
- UPC: 00072845129031
- Voltage: 12V
- Weight (lbs): 2.21
- Wire Harness Included: Yes
- Part Description: Fuel Pump Module Assembly
$66.56
Delphi® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: FG0052Product Specifications- Notes: RPO Code NE2;with Plastic Tank;with 18 Gallon Tank;Original design w/o Check Valve. Must only be used to replace fuel pump modules built w/o check valve. If you are unsure if your module has a check valve, then use FG0287; Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 10
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 109.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 40.0
- Resistance Ohms Full: 250.0
- Strainer Included: Yes
- System Pressure: 62 psi
- Terminal Gender: Male
- Terminal Quantity: 4
- Terminal Type: Blade
- UPC: 689604059890
- Vapor Pressure Sensor: Yes
- Voltage: 13.0 VDC
- Part Description: Fuel Pump Module Assembly
$173.12
Airtex® In-Tank Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: E3953MProduct Specifications- Notes: w/Metal Tank; Except Export; Turbine Pump Technology; Includes Wiring Harness, Terminals & Tank Seal
- Gasket Included: Y
- Hazardous Material: No
- Inlet Count: 1
- Inlet Type: Strainer
- Item Grade: Standard Replacement
- Maximum Free Flow Rate (gph): 55
- Maximum Pressure Rate (psi): 90
- Minimum Free Flow Rate (gph): 45
- Minimum Pressure Rate (psi): 70
- Outlet Count: 1
- Outlet Size: 3/8"
- Outlet Type: Quick Connect, Return Line
- Package Contents: Pump & Kit
- Package Quantity: 1
- Warranty: Lifetime Limited Warranty
- Part Description: In-Tank Fuel Pump Module Assembly
OEM (Genuine) 1998 Oldsmobile Bravada Module
PartNumber: 19369950
Product Specifications- Notes: S-Series; 4.3l; Blazer/Jimmy/Bravada
- Other Names: Fuel Pump, Module
- Fitment Type: Direct Replacement
- Replaces: 19331273, 25344816, 25178732, 25314775, 19177256, 25320511, 25168012
- Part Description: Module
Denso® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: 953-0017Product Specifications- Notes: Exc 18 Gallon Fuel Tank; DENSO Solution Module Assy-Turbine Pump & Design Upgrade Over OE
- Gaskets Included: Yes
- Internet Product Code (IPC): E81DC40CD13
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-0017
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511193352
- Part Description: Fuel Pump Module Assembly
Hella® Fuel Pump for 1998 Oldsmobile Bravada
PartNumber: H75031011Product Specifications- Notes: Discontinued; Exc 18 Gallon Gas Tank; 12V
- UPC: 760687051961
- Part Description: Fuel Pump
Denso® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: 953-0021Product Specifications- Notes: w/18 Gallon Fuel Tank; DENSO Solution Module Assy-Turbine Pump & Design Upgrade Over OE
- Gaskets Included: Yes
- Internet Product Code (IPC): 00821518BFA
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-0021
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511193390
- Part Description: Fuel Pump Module Assembly
Denso® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: 953-5032Product Specifications- Notes: w/18 Gallon Fuel Tank - Sell out reorder 953-0021
- Gaskets Included: Yes
- Internet Product Code (IPC): EC2F71E3408
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5032
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511163461
- Part Description: Fuel Pump Module Assembly
Autobest® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: HP2903AProduct Specifications- Gasket or Seal Included: Yes
- Height (in.): 10.4
- Inlet Size: 0.362
- Inlet Type: Strainer
- Internal or External: Internal
- Length (in.): 13.6
- Life Cycle Status Code: Superseded
- Maximum Free Flow (GPH): 82.225
- Maximum Pump Pressure (PSI): 145
- Minimum Free Flow (GPH): 69.805
- Minimum Pump Pressure (PSI): 87
- Outlet Size: 0.374
- Outlet Type: Quick Connect
- Package Contents: Pump & Module
- Pump Type: Turbine
- Regulator Included: No
- Short Description: High Performance Fuel Pump
- Superseded To: F2903A
- UPC: 072845169037
- Weight (lbs.): 4
- Width (in.): 6.9
- Part Description: Fuel Pump Module Assembly
Denso® Fuel Pump Module Assembly for 1998 Oldsmobile Bravada
PartNumber: 953-5035Product Specifications- Notes: Exc 18 Gallon Fuel Tank - Sell out reorder 953-0017
- Gaskets Included: Yes
- Internet Product Code (IPC): D574E8A5B2E
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-5035
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- UPC: 042511163492
- Part Description: Fuel Pump Module Assembly
