Notes: Engine Family Number WFMXT04.2AAA;Engine Family Number WG9XA05.4JGC;Engine Family Number WG9XA05.46BF;Engine Family Number WG9XA05.45BF;Engine Family Number WFMXA04.2AAA;Engine Family Number WFMXA04.6BAA;Engine Family Number WG9XA05.4HGC;Engine Family Number WFMXT04.6AAA;Engine Family Number WFMXA05.4HBC;Engine Family Number WFMXA05.4JBN;CARB Executive Order D-193-103;Engine Family Number WFMXA04.6AAA;Certification Level : LEV1 LEV; OE Spec; Cutting & Welding Reqd During Installation;Certification Level : TIER1; OE Spec; Cutting & Welding Reqd During Installation
Air Tube Adaptable: No
Body Height: 3.5
Body Length: 7.75
Body Material: Stainless Steel
Body Shape: Oval
Body Type: Clam Shell
Body Width: 5.25
Finish: Stainless Steel
Heat Shield Attached: No
Inlet Attachment: Weld-On
Inlet Diameter: 2.5
Inlet Orientation: Angled
Inlet Quantity: 1
Material: Stainless Steel
Outlet Attachment: Weld-On
Outlet Diameter: 2.5
Outlet Orientation: Straight
Outlet Quantity: 1
Overall Length: 11.5
Oxygen Sensor Location: None
Sensor Port Count: 0
Series: California
Substrate Material: Ceramic
Title: California Universal
UPC: 841380069733
Part Description: 1998 Ford F-150 OBDII Universal Fit Oval Body Catalytic Converter
Notes: CARB Executive Order D-193-103;Engine Family Number WFMXA04.6BAA;Engine Family Number WFMXT04.6AAA;Engine Family Number WFMXA04.2AAA;Engine Family Number WFMXT04.2AAA;Engine Family Number WFMXA04.6AAA;Certification Level : TIER1; OE Spec; Cutting & Welding Reqd During Installation
Air Tube Adaptable: No
Body Height: 3.75
Body Length: 12
Body Material: Stainless Steel
Body Shape: Oval
Body Type: Clam Shell
Body Width: 5.5
Finish: Stainless Steel
Heat Shield Attached: Yes
Heat Shield Included: Yes
Heat Shield Material: Aluminized Steel
Inlet Attachment: Weld-On
Inlet Diameter: 2.5
Inlet Orientation: Straight
Inlet Quantity: 1
Material: Stainless Steel
Outlet Attachment: Weld-On
Outlet Diameter: 2.5
Outlet Orientation: Straight
Outlet Quantity: 1
Overall Length: 16
Oxygen Sensor Location: Midbed
Sensor Port Count: 1
Series: California
Substrate Material: Ceramic
Title: California Universal
UPC: 841380069696
Part Description: 1998 Ford F-150 OBDII Universal Fit Oval Body Catalytic Converter
Notes: Engine Family Number WFMXA05.4HBC;CARB Executive Order D-193-103;Engine Family Number WG9XA05.46BF;Engine Family Number WG9XA05.45BF;Engine Family Number WFMXA05.4JBN;Engine Family Number WG9XA05.4HGC;Engine Family Number WG9XA05.4JGC;Certification Level : TIER1; OE Spec; Cutting & Welding Reqd During Installation;Certification Level : LEV1 LEV; OE Spec; Cutting & Welding Reqd During Installation
Air Tube: No
Body Type: Clam Shell
Catalytic Converter Body Length: 9"
Catalytic Converter Body Shape: Oval
Catalytic Converter Format: Pre-Catalytic Converter and Main Catalytic Converter
Catalytic Converter Overall Length: 13"
Catalytic Converter Oxygen Sensor Location: None
Catalytic Converter Substrate Material: Ceramic
Catalytic Converter Width: 5.5"
Catalytic Inlet Diameter: 2.5"
Catalytic Outlet Diameter: 2.5"
Catalytic Series: OBDII
Converter Body Material: Stainless Steel
Converter Configuration: Universal Fit
Inlet Connection Type: Weld-On
Inlet Position: Center
Installation Complexity: Professional Installation Recommended
Main Piping Diameter: 2.5"
O2 Sensor Port: No
Outlet Connection Type: Weld-On
Outlet Position: Center
Position: Rear
Part Description: 1998 Ford F-150 OBDII Universal Fit Oval Body Catalytic Converter
Notes: Engine Family Number WFMXA04.6BAA;Engine Family Number WFMXT04.6AAA;Engine Family Number WFMXA04.6AAA;CARB Executive Order D-193-103;Certification Level : TIER1
Air Tube Adaptable: No
Body Material: Stainless Steel
Body Type: Clam-Shell
Clamp Included: Yes
Color/Finish: Stainless Steel
Converter Quantity: 1
Heat Shield Included: Yes
Inlet Attachment: Bolt-On
Material: Stainless Steel
Mounting Hardware Included: Yes
Overall Length: 50.75
Series: California
Substrate Material: Ceramic
Title: California Direct-Fit
Type: Direct-Fit
UPC: 841380071217
Part Description: 1998 Ford F-150 OBDII Direct Fit Catalytic Converter
