Dorman® Fuel Tank Sending Unit for 1994 Chrysler Town & Country
PartNumber: 2630312Product Specifications- Connector Color: White
- Connector Gender: Female
- Connector Shape: Flat Plug
- Height: 350 mm
- Housing Length: 189 mm
- Housing Material: Plastic (Polyoxymethylene)
- Housing Width: 84 mm
- Inlet Diameter: 6.5 mm
- Length: 57 mm
- Lock Ring Included: No
- Maximum Flow Rating: 100 LPH
- Maximum Pressure: 0.32 MPA
- OE Part Number: 4682761AB
- Outlet Diameter: 6.5 mm
- Outlet Quantity: 1
- Outlet Type: Male
- Seal Included: Yes
- Terminal Gender: Female
- Terminal Quantity: 4
- Terminal Type: Spade
- Universal Or Specific Fit: Specific
- UPC: 747214016433
- Width: 6.35 mm
- Wire Gauge Measurement: 1.5 AWG
- Wire Quantity: 4
- Part Description: Fuel Tank Sending Unit
$121.92
Delphi® Fuel Pump Module Assembly for 1994 Chrysler Town & Country
PartNumber: FG0195Product Specifications- Notes: Wire Harness Tag FA10002;Fuel tank contamination is the leading cause of premature fuel pump failure. To reduce risk of contaminating the replacement pump, Delphi recommends cleaning the fuel tank before installing a new pump. Use of fuel tank cleaning kit FC01 is recommended.
- Current Draw: 14
- Flow Rating: 18 gph
- Fuel Level Sender Assembly Included: Yes
- Fuel Type: Gas
- Gasket or Seal Included: Yes
- In Tank or External: In Tank
- Inlet Type: Strainer
- Internal or External Strainer: Internal
- Item Grade: Standard Replacement
- Maximum Pressure: 80.0 PSI
- Outlet Outside Diameter: 0.375''
- Outlet Quantity: 3
- Outlet Type: Quick Connect
- Pump Type: Electric
- Regulator Included: No
- Resistance Ohms Empty: 4.0
- Resistance Ohms Full: 102.0
- Strainer Included: Yes
- System Pressure: 48 psi
- Terminal Gender: Male
- Terminal Quantity: 3
- Terminal Type: Blade
- UPC: 689604061329
- Vapor Pressure Sensor: No
- Voltage: 12.0 VDC
- Part Description: Fuel Pump Module Assembly
$156.86
Autobest® Fuel Pump Module Assembly for 1994 Chrysler Town & Country
PartNumber: F3088AProduct Specifications- Notes: Includes Fuel Pump, Sending Unit, Float, Fuel Reservoir, Fuel Strainer and Tank Seal
- Average Current Draw(A): 8.5
- Average Flow Rating(GPH): 31.8
- Connector Gender: Female
- Connector Quantity: 1
- Connector Shape: Rectangle
- Country of Orign: China
- Fuel Filter Included: No
- Fuel Sending Unit Included: Yes
- Fuel Tank Pressure Sensor Included: No
- Gasket or Seal Included: Yes
- Gasket Or Seal Material: FKM
- Grade Type: Regular
- Housing Material: POM
- In Tank or External: In Tank
- Inlet Size: 0.504
- Inlet Type: Strainer
- Installation Warnings: No
- Internal Or External Strainer: Internal
- Lock Ring Included: No
- Maximum Pump Pressure (PSI): 119
- Minimum Pump Pressure (PSI): 89.9
- Mounting Hardware Included: No
- Negative Ground: No
- Outlet Quantity: 1
- Outlet Size: 3/8
- Outlet Type: Quick Connect
- Product Height (in): 4.92
- Product Length (in): 16.14
- Product Width (in): 6.3
- Pump Type: Turbine
- Regulator Included: No
- Resistance Ohms Empty: 104
- Resistance Ohms Full: 3
- Strainer Included: Yes
- Terminal Gender: Male
- Terminal Quantity: 3
- Terminal Type: PIN
- UPC: 00072845130884
- Voltage: 12V
- Weight (lbs): 2.71
- Wire Harness Included: No
- Part Description: Fuel Pump Module Assembly
$72.37
OEM (Genuine) 1994 Chrysler Town & Country Fuel Pump
PartNumber: 4682761AB
Product Specifications- Notes: 2WD
- Item Dimensions: 18.2 x 5.6 x 4.4 inches
- Item Weight: 2.60 Pounds
- Part Description: Fuel Pump
Denso® Fuel Pump And Strainer Set for 1994 Chrysler Town & Country
PartNumber: 950-3027Product Specifications- Notes: OE / OES Replacement Fuel Pump & Strainer Kit;OE Replacement Fuel Pump & Strainer Kit
- Fuel Pump Type: Electrical
- Gaskets Included: Yes
- Internet Product Code (IPC): 832C0DC8060
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 950-3027
- MFG Name: DENSO
- Package Contents: Fuel Pump Kit
- Pump Placement: In Tank
- Supplier Company Name: DENSO
- UPC: 042511170834
- Part Description: Fuel Pump And Strainer Set
Airtex® In-Tank Fuel Pump Module Assembly for 1994 Chrysler Town & Country
PartNumber: E7030MProduct Specifications- Notes: Improved Design w/Int Strainer; 3 Pin Connector on Module
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 1469AC79260
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 110
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E7030M
- Minimum Pressure (psi): 90
- Outlet Attachment: Outlet-HoseBarb
- Outlet Size: 5/16
- Outlet Type: HOSE BARB, RETURN LINE
- Package Contents: Fuel Pump Module Assembly
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044137092
- Wiring Harness Included: No
- Part Description: In-Tank Fuel Pump Module Assembly
OEM (Genuine) 1994 Chrysler Town & Country Fuel Pump
PartNumber: 4778436Product Specifications- Notes: All Models; 3.8l; W/AWD
- Part Description: Fuel Pump
Denso® Fuel Pump Module Assembly for 1994 Chrysler Town & Country
PartNumber: 953-3000Product Specifications- Notes: OE Replacement Module Assy
- Gaskets Included: Yes
- Internet Product Code (IPC): 123F929D890
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-3000
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511095403
- Part Description: Fuel Pump Module Assembly
Airtex® Electric Fuel Pump for 1994 Chrysler Town & Country
PartNumber: E7057MProduct Specifications- Notes: 3 Pin Connector on Module
- Gasket or Seal Included: Yes
- Inlet Attachment: Inlet-Strainer
- Inlet Type: STRAINER
- Internal or External: Internal
- Internet Product Code (IPC): 029B36E197E
- Item Grade: OEM Standard Part
- Item has MSDS (SDS): No
- Maximum Pressure (psi): 90
- MFG Brand Name: Airtex Products
- MFG Model # (Series): E7057M
- Minimum Pressure (psi): 48.0
- Outlet Attachment: Outlet-QuickConnect
- Outlet Size: Outlet - 5/16
- Outlet Type: QUICK CONNECT, RETURN LINE
- Package Contents: PUMP & KIT
- Package Quantity: 1
- Pump Type: Electrical
- Supplier Company Name: Airtex Products
- UPC: 080044140498
- Voltage [V]: 12V
- Wiring Harness Included: No
- Part Description: Electric Fuel Pump
OEM (Genuine) 1994 Chrysler Town & Country Fuel Pump
PartNumber: 5217826Product Specifications- Notes: 4WD
- Part Description: Fuel Pump
Denso® Fuel Pump Module Assembly for 1994 Chrysler Town & Country
PartNumber: 953-6006Product Specifications- Gaskets Included: Yes
- Internet Product Code (IPC): 34179F9DBB3
- Item Grade: Premium Replacement
- Item has MSDS (SDS): Y
- Meets or Exceeds Original Equipment Manufacture Specifications: YES
- MFG Brand Name: DENSO Auto Parts
- MFG Model # (Series): 953-6006
- MFG Name: DENSO
- Package Contents: Fuel Pump Module
- Seal And Lock Ring Included: NO
- Supplier Company Name: DENSO
- Universal Or Specific Fit: Specific
- UPC: 042511171213
- Part Description: Fuel Pump Module Assembly
