National® Automatic Transmission Output Shaft Seal 223540

National Automatic Transmission Output Shaft Seal 223540
$6.09
In Stock. Ships in 1-3 Business Days

Vehicle Specific

Check if it fits by entering your vehicle info
Select Your Vehicle
  • Specifications
  • Features
  • Vehicle Fitment
  • Specifications

    BrandNational
    Part Number223540
    Part DescriptionAutomatic Transmission Output Shaft Seal
    Helix TypeBi-Directional Lip Design
    Housing Bore (Inch)2.165 in
    Housing Bore (mm)55.000 mm
    Inside Diameter (Inch)1.378 in
    Inside Diameter (mm)35.000 mm
    MaterialPolyacrylate
    Outside Diameter (Inch)2.183 in
    Outside Diameter (mm)55.450 mm
    Overall Width with Side Lip (Inch)0.610 in
    Overall Width with Side Lip (mm)15.500 mm
    Sealing MaterialPolyacrylate
    Series220000
    Shaft (Inch)1.378 in
    Shaft (mm)35.000 mm
    Thickness (Inch)0.315 in
    Thickness (mm)9.000 mm
    Type40
    Width (Inch)0.315 in
    Width (mm)9.000 mm
    Warning: California’s Proposition 65
  • Features

    National Automatic Transmission Output Shaft Seal are featured as follows:
    • The purpose of these seals is to improve wheel end uptime by efficiently excluding dirt, moisture, and other substances.
    • This includes the National Dynamic Edge technology that uses a patented pending system for maximum protection.
    • These are designed to help avoid pre-mature bearing failure.
    • This ensures durability beyond any other conditions in existence.
    • To fit OE's configurations, national has constructed them.
    • Performance-engineered and life-long operating.
    • They have a sinusoidal wave design that diverts contaminants from the seal.
    • Maximum protection against environmental contamination under unfavorable situations.
    The National Automatic Transmission Output Shaft Seal 223540 is a high performance product designed to increase wheel end reliability by effectively excluding dirt, moisture and other contaminants. It utilizes a patent pending National Dynamic Edge technology for maximum protection and helps prevent premature bearing failure. Constructed to meet original equipment configurations and is known for its unmatched durability under the most grueling conditions. It is a product of National as a brand of the Federal Mogul Corporation. Renowned for offering premium products that meet or exceed the original equipment requirements across a wide range of wheel bearings and oil seal needs. The seal is engineered to perfectly fit your vehicle and provide long service life.
    Federal-Mogul Corporation's National, a brand that has been in the automotive, agricultural and industrial markets since 75 years. It is famous for its premium products which are equal to or better than OE standards especially on wheel bearings and oil seals. The company uses most recent technologies and equipment, coupled with its knowledge to achieve the highest standards when designing, manufacturing and testing each product.
  • Vehicle Fitment

    Year Make Model Trim Engine
    1961-1964 BMW 1500All TrimsAll Engines
    1964-1971 BMW 1600All TrimsAll Engines
    1966-1971 BMW 1600-2All TrimsAll Engines
    1966-1968 BMW 1600tiAll TrimsAll Engines
    1967-1971 BMW 1602All TrimsAll Engines
    1964-1971 BMW 1800All TrimsAll Engines
    1964-1967 BMW 1800tiAll TrimsAll Engines
    1971 BMW 1802All TrimsAll Engines
    1966-1972 BMW 2000All TrimsAll Engines
    1965-1970 BMW 2000cAll TrimsAll Engines
