Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Gates |
Part Number | 33946 |
Part Description | Oe Type Engine Coolant Thermostat |
By-Pass Flange Diameter | 1.19" |
Depth from Flange | 1.41" |
Design | Bottom By-Pass |
Flange Diameter | 2.12" |
Height from Flange | 0.73" |
Includes Installation Tool | No |
Jiggle Pin/Check Valve | No |
Material | Steel, Copper |
Number of Gaskets | 0 |
Number of Seals | 1 |
OE Comparison Rating | OE Performance |
Seal Type | O-Ring |
Temperature (C) | 85 |
Temperature (F) | 185 |
Total Height | 2.09" |
Type | OE Type Thermostat |
UPC | 072053877298 |
Year Make Model | Trim | Engine |
---|---|---|
2006-2016 Chevrolet Express 2500 | All Trims | 8 Cyl 6.6L |
2006-2016 Chevrolet Express 3500 | All Trims | 8 Cyl 6.6L |
2001-2019 Chevrolet Silverado 2500 HD | All Trims | 8 Cyl 6.6L |
2007 Chevrolet Silverado 2500 HD Classic | All Trims | 8 Cyl 6.6L |
2001-2006 Chevrolet Silverado 3500 | All Trims | 8 Cyl 6.6L |
2007 Chevrolet Silverado 3500 Classic | All Trims | 8 Cyl 6.6L |
2007-2019 Chevrolet Silverado 3500 HD | All Trims | 8 Cyl 6.6L |
2006-2016 GMC Savana 2500 | All Trims | 8 Cyl 6.6L |
2006-2016 GMC Savana 3500 | All Trims | 8 Cyl 6.6L |
2001-2016 GMC Sierra 2500 HD | All Trims | 8 Cyl 6.6L |
