Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 97489 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 3.9375 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | MSC105CG1 |
Discharge Port Type | Sealing Washer |
Distance From Clutch To Mounting Flange | 1.40625 |
Mount Distance MM | 35.560 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24404] / Slimline Washer |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24402] / Slimline Washer |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 100.025 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 3.9375 |
Pulley Outside Diameter | 3.9375 |
Pulley Ridge Diameter | 3.9375 |
Refrigerant Type | R134a |
Suction Port Type | Sealing Washer |
Switch Included | Heat Switch |
Terminal Type | Butt Connector |
UPC | 096361974890 |
Year Make Model | Trim | Engine |
---|---|---|
2005 Buick Terraza | All Trims | All Engines |
2006 Buick Terraza | All Trims | 6 Cyl 3.5L |
2005 Chevrolet Uplander | All Trims | All Engines |
2006 Chevrolet Uplander | All Trims | 6 Cyl 3.5L |
2005-2006 Pontiac Montana | All Trims | 6 Cyl 3.5L |
2005 Saturn Relay | All Trims | All Engines |
2006 Saturn Relay | All Trims | 6 Cyl 3.5L |
2006 Saturn Relay | All Trims | 6 Cyl 3.9L |
