Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 97379 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.3125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 7SEU16C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.500 |
ECV Harness Connector | Compressor SE03F / SE03R-F, Vehicle SE03M / SE03R-M |
Mount Distance MM | 38.100 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24670] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24635] / Green Round O-Ring |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 109.550 |
Pulley Groove Quantity | 7 |
Pulley Lip Diameter | 4.3125 |
Pulley Outside Diameter | 4.3125 |
Pulley Ridge Diameter | 4.3125 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Lead Wire |
UPC | 096361973794 |
Year Make Model | Trim | Engine |
---|---|---|
2007 Audi A8 Quattro | All Trims | 12 Cyl 6.0L |
2009 Audi A8 Quattro | All Trims | 12 Cyl 6.0L |
2005-2006 Porsche Cayenne | All Trims | 6 Cyl 3.2L |
2008-2010 Porsche Cayenne | All Trims | 6 Cyl 3.6L |
2008-2010 Porsche Cayenne | Base | 6 Cyl 3.6L |
2017 Porsche Cayenne | All Trims | 6 Cyl 3.6L |
2018 Porsche Cayenne | Base | 6 Cyl 3.6L |
2018 Porsche Cayenne | Platinum Edition | 6 Cyl 3.6L |
2002-2004 Volkswagen Passat | All Trims | 8 Cyl 4.0L |
2004-2006 Volkswagen Phaeton | All Trims | 12 Cyl 6.0L |
