Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 97366 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.250 |
Coil Clock Position | NR |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 7SEU17C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.65625 |
ECV Harness Connector | Compressor SE05F, Vehicle SE22M |
Mount Distance MM | 16.510 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24670] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24635] / Green Round O-Ring |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 107.950 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.250 |
Pulley Outside Diameter | 4.250 |
Pulley Ridge Diameter | 4.250 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Butt Connector |
UPC | 096361973664 |
Year Make Model | Trim | Engine |
---|---|---|
2004-2012 Mercedes-Benz G500 | All Trims | All Engines |
2004-2005 Mercedes-Benz G55 AMG | All Trims | All Engines |
2008-2011 Mercedes-Benz G55 AMG | All Trims | All Engines |
2009-2012 Mercedes-Benz G550 | All Trims | All Engines |
1998-2003 Mercedes-Benz ML320 | All Trims | All Engines |
2003-2005 Mercedes-Benz ML350 | All Trims | All Engines |
1998-2001 Mercedes-Benz ML430 | All Trims | All Engines |
2002-2005 Mercedes-Benz ML500 | All Trims | All Engines |
2001-2003 Mercedes-Benz ML55 AMG | All Trims | All Engines |
