Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 77487 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 3.640625 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | MSC105C |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 2.9375 |
Mount Distance MM | 74.676 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24131] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24679] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 92.456 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 3.640625 |
Pulley Outside Diameter | 3.640625 |
Pulley Ridge Diameter | 3.640625 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Switch Included | Heat Switch |
Terminal Type | Pin |
UPC | 096361774872 |
Year Make Model | Trim | Engine |
---|---|---|
1997-1999 Mitsubishi Montero Sport | All Trims | 6 Cyl 3.0L |
1999 Mitsubishi Montero Sport | All Trims | 4 Cyl 2.4L |
1999 Mitsubishi Montero Sport | All Trims | 6 Cyl 3.5L |
2000-2004 Mitsubishi Montero Sport | All Trims | All Engines |
