Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 67402 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.3125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | SS120DL1 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 0.921875 |
Mount Distance MM | 23.368 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24659] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24642] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 109.550 |
Pulley Groove Quantity | 5 |
Pulley Lip Diameter | 4.3125 |
Pulley Outside Diameter | 4.3125 |
Pulley Ridge Diameter | 4.3125 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Switch Included | Heat Switch |
Terminal Type | Lead Wire |
UPC | 096361674028 |
Year Make Model | Trim | Engine |
---|---|---|
2001-2002 BMW Z3 | All Trims | 6 Cyl 2.5L |
2001-2002 BMW Z3 | All Trims | 6 Cyl 3.0L |
2001-2002 BMW Z3 | All Trims | 6 Cyl 3.2L |
