Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 67317 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.6875 |
Coil Clock Position | NR |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 6SEU16C |
Discharge Port Type | O-Ring / Gasket |
Distance From Clutch To Mounting Flange | 0.640625 |
ECV Harness Connector | Compressor SE10F, Vehicle SE10M |
Mount Distance MM | 16.256 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24068] / Gasket |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24069] / Gasket |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 119.050 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.6875 |
Pulley Outside Diameter | 4.6875 |
Pulley Ridge Diameter | 4.6875 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring / Gasket |
Switch Included | Control Valve |
Terminal Type | Butt Connector |
UPC | 096361673175 |
Year Make Model | Trim | Engine |
---|---|---|
2007-2008 Chrysler Sebring | All Trims | 6 Cyl 2.7L |
2007-2008 Chrysler Sebring | All Trims | 6 Cyl 3.5L |
2008 Dodge Avenger | All Trims | 6 Cyl 2.7L |
2008 Dodge Avenger | All Trims | 6 Cyl 3.5L |
