Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 67301 |
Part Description | Remanufactured A C Compressor With Clutch |
Belt Width IN | 0.625 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.625 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 10PA15C |
Distance From Clutch To Mounting Flange | 2.953125 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New Compressor w/o Clutch | [58341] |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24156] / Compressor Manifold Port Gasket |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 142.748 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 5.625 |
Pulley Outside Diameter | 5.625 |
Pulley Ridge Diameter | 5.625 |
Refrigerant Type | R134a |
Reman w/o Clutch | [57341] |
Suction Port Type | Pad Mount |
Terminal Type | Butt |
UPC | 096361673014 |
Year Make Model | Trim | Engine |
---|---|---|
1989 Dodge Raider | All Trims | All Engines |
1989-1991 Mitsubishi Montero | All Trims | All Engines |
1988-1994 Toyota Pickup | All Trims | 6 Cyl 3.0L |
1993 Toyota T100 | All Trims | All Engines |
1994 Toyota T100 | All Trims | 6 Cyl 3.0L |
