Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57574 |
Part Description | Remanufactured A C Compressor With Clutch |
Belt Width IN | 0.500 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.000 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Comp Head Prt Config | Top-Vert-Pad |
Compatible Refrigerant Oil Type | PAG 100 |
Compressor Head Type | UK |
Compressor Type | SD708 |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.250 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24681] / Green O-Ring |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24661] / Green O-Ring |
O-Ring B Quantity | 1 |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 127.000 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 5.000 |
Pulley Outside Diameter | 5.000 |
Pulley Ridge Diameter | 5.000 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring |
Terminal Type | Butt |
UPC | 096361575745 |
Year Make Model | Trim | Engine |
---|---|---|
1986 Mazda RX-7 | All Trims | All Engines |
1987-1990 Mazda RX-7 | All Trims | 2 Cyl 1.3L |
