Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57553 |
Part Description | Remanufactured A C Compressor With Clutch |
Belt Width IN | 1.000 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Comp Head Prt Config | Top-Horiz-Pad-SealingWasher |
Compatible Refrigerant Oil Type | PAG 100 |
Compressor Head Type | GF |
Compressor Type | SD7H15 |
Discharge Port Type | Sealing Washer |
Distance From Clutch To Mounting Flange | 1.046875 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24354] / Sealing Washer |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 130.048 |
Pulley Groove Quantity | 7 |
Pulley Lip Diameter | 5.125 |
Pulley Outside Diameter | 5.125 |
Pulley Ridge Diameter | 5.125 |
Refrigerant Type | R134a |
Suction Port Type | Sealing Washer |
Terminal Type | Pin |
UPC | 096361575530 |
w/ Diode | Yes |
Year Make Model | Trim | Engine |
---|---|---|
1994-1999 Dodge Dakota | All Trims | 8 Cyl 5.2L |
1994-2001 Dodge Dakota | All Trims | 6 Cyl 3.9L |
1998-2001 Dodge Dakota | All Trims | 8 Cyl 5.9L |
1998-1999 Dodge Durango | All Trims | All Engines |
2000 Dodge Durango | All Trims | 8 Cyl 5.2L |
2000-2001 Dodge Durango | All Trims | 8 Cyl 5.9L |
1994-1995 Dodge Ram 1500 | All Trims | All Engines |
1996 Dodge Ram 1500 | All Trims | 6 Cyl 3.9L |
1996 Dodge Ram 1500 | All Trims | 8 Cyl 5.2L |
1996 Dodge Ram 1500 | All Trims | 8 Cyl 5.9L |
