Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57541 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.875 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 100 |
Compressor Type | DKV11A |
Discharge Port Type | O-Ring |
Distance From Clutch To Mounting Flange | 1.250 |
Mount Distance MM | 31.750 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24404] / Slimline Washer |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24402] / Slimline Washer |
O-Ring B Quantity | 1 |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 123.825 |
Pulley Groove Quantity | 5 |
Pulley Lip Diameter | 4.875 |
Pulley Outside Diameter | 4.875 |
Pulley Ridge Diameter | 4.875 |
Refrigerant Type | R134a |
Suc Prt Typ Note | Stepped Port in Middle |
Suction Port Type | O-Ring |
Switch Service Port | w/o Switch Port |
Terminal Type | Bullet |
UPC | 096361575417 |
Year Make Model | Trim | Engine |
---|---|---|
1999-2002 Saturn SC1 | All Trims | All Engines |
1999-2002 Saturn SC2 | All Trims | All Engines |
1999-2002 Saturn SL | All Trims | All Engines |
1999-2002 Saturn SL1 | All Trims | All Engines |
1999-2002 Saturn SL2 | All Trims | All Engines |
1999 Saturn SW1 | All Trims | All Engines |
1999-2001 Saturn SW2 | All Trims | All Engines |
