Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57396 |
Part Description | Remanufactured A C Compressor With Clutch |
Belt Width IN | 0.500 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.250 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 10PA17K |
Distance From Clutch To Mounting Flange | 2.40625 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24156] / Compressor Manifold Port Gasket |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 133.350 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 5.250 |
Pulley Outside Diameter | 5.250 |
Pulley Ridge Diameter | 5.250 |
Refrigerant Type | R134a |
Reman w/o Clutch | [57383] / Clutch Assembly |
Suction Port Type | Pad Mount |
Terminal Type | Pin |
UPC | 096361573963 |
Year Make Model | Trim | Engine |
---|---|---|
1993 Dodge Caravan | All Trims | 6 Cyl 3.3L |
1993-1995 Dodge Caravan | All Trims | 6 Cyl 3.0L |
1993 Dodge Grand Caravan | All Trims | 6 Cyl 3.3L |
1993-1995 Dodge Grand Caravan | All Trims | 6 Cyl 3.0L |
1993-1995 Plymouth Grand Voyager | All Trims | 6 Cyl 3.0L |
1993-1995 Plymouth Voyager | All Trims | 6 Cyl 3.0L |
