Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57363 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.875 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 10P15C |
Distance From Clutch To Mounting Flange | 1.546875 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24613] / Green O-Ring |
O-Ring A Quantity | 4 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 123.825 |
Pulley Groove Quantity | 4 |
Pulley Lip Diameter | 4.875 |
Pulley Outside Diameter | 4.875 |
Pulley Ridge Diameter | 4.875 |
Refrigerant Type | R134a |
Reman w/o Clutch | [57373] / Clutch Assembly |
Suc Prt Typ Note | w/O-Ring |
Suction Port Type | Pad Mount |
Terminal Type | Butt |
UPC | 096361573635 |
Year Make Model | Trim | Engine |
---|---|---|
1986-1987 Acura Legend | All Trims | 6 Cyl 2.5L |
1987-1990 Acura Legend | All Trims | 6 Cyl 2.7L |
