Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57154 |
Part Description | Remanufactured A C Compressor With Clutch |
Belt Width IN | 0.625 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.250 |
Coil Clock Position | 12 |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | FS10 |
Distance From Clutch To Mounting Flange | 3.171875 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24632] / Green O-Ring |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 133.350 |
Pulley Groove Quantity | 4 |
Pulley Lip Diameter | 5.250 |
Pulley Outside Diameter | 5.250 |
Pulley Ridge Diameter | 5.250 |
Refrigerant Type | R134a |
Suc Prt Typ Note | W/ O-Ring |
Suction Port Type | Block Mount |
Terminal Type | Harness Connector |
UPC | 096361571549 |
Year Make Model | Trim | Engine |
---|---|---|
1995-1997 Hyundai Accent | All Trims | All Engines |
1994-1995 Hyundai Elantra | All Trims | All Engines |
1990-1991 Hyundai Sonata | All Trims | 6 Cyl 3.0L |
1992-1998 Hyundai Sonata | All Trims | All Engines |
