Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 57103 |
Part Description | Remanufactured A C Compressor With Clutch |
Belt Width IN | 0.4375 |
Clutch Included | Yes |
Clutch Maximum Diameter | 5.750 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | C171 |
Discharge Port Type | O-Ring / Gasket |
Distance From Clutch To Mounting Flange | 2.250 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | [24151] / Compressor Manifold Port Gasket |
O-Ring A Quantity | 2 |
O-Ring B Number/Desc | Not Required |
O-Ring B Quantity | NR |
Pulley Belt Type | V-Belt |
Pulley Diameter MM | 146.050 |
Pulley Groove Quantity | 1 |
Pulley Lip Diameter | 5.750 |
Pulley Outside Diameter | 5.750 |
Pulley Ridge Diameter | 5.750 |
Refrigerant Type | R134a |
Reman w/o Clutch | [57038] / Clutch Assembly |
Suc Prt Typ Note | W/ O-Ring |
Suction Port Type | O-Ring / Gasket |
Terminal Type | Spade |
UPC | 096361571037 |
Year Make Model | Trim | Engine |
---|---|---|
1985 Dodge B150 | All Trims | 6 Cyl 3.7L |
1985 Dodge B250 | All Trims | 6 Cyl 3.7L |
1985 Dodge D100 | All Trims | 6 Cyl 3.7L |
1985 Dodge D150 | All Trims | 6 Cyl 3.7L |
1985 Dodge D250 | All Trims | 6 Cyl 3.7L |
1985 Dodge D350 | All Trims | 6 Cyl 3.7L |
1984 Dodge Mini Ram | All Trims | 4 Cyl 2.2L |
1985 Dodge W100 | All Trims | 6 Cyl 3.7L |
1985 Dodge W150 | All Trims | 6 Cyl 3.7L |
