Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 197395 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.000 |
Coil Clock Position | Lead Wire |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | SCSA08H |
Distance From Clutch To Mounting Flange | 1.8125 |
Mounting Hardware | Not Included |
Mounting Type | Ear Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | 24661 |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | 24681 |
O-Ring B Quantity | 1 |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.000 |
Pulley Outside Diameter | 4.000 |
Pulley Ridge Diameter | 4.000 |
Refrigerant Type | R134a |
Terminal Type | Lead Wire |
UPC | 096361087682 |
Year Make Model | Trim | Engine |
---|---|---|
2013-2016 Scion FR-S | All Trims | All Engines |
2013-2015 Subaru BRZ | All Trims | All Engines |
2017-2018 Toyota 86 | All Trims | All Engines |
