Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 197387 |
Part Description | Remanufactured A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.500 |
Coil Clock Position | Lead Wire |
Coil Type | Coil Less |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | VS16E |
Distance From Clutch To Mounting Flange | 2.828125 |
ECV Harness Connector | Compressor SE25F, Vehicle SE22M |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | Remanufactured |
O-Ring A Number/Desc | 24131 |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | 24622 |
O-Ring B Quantity | 1 |
O-Ring C Number/Desc | Not Required |
O-Ring C Quantity | NR |
Pulley Belt Type | Serpentine |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.500 |
Pulley Outside Diameter | 4.500 |
Pulley Ridge Diameter | 4.500 |
Refrigerant Type | R134a |
Terminal Type | Lead Wire |
UPC | 096361090644 |
Year Make Model | Trim | Engine |
---|---|---|
2012-2017 Hyundai Azera | All Trims | All Engines |
2014-2016 Kia Cadenza | All Trims | All Engines |
