Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 198370 |
Part Description | Rear A C Compressor With Clutch |
Clutch Included | Yes |
Clutch Maximum Diameter | 4.703125 |
Coil Clock Position | Wire Lead |
Coil Voltage | 12 |
Compatible Refrigerant Oil Type | PAG 46 |
Compressor Type | 10S17C |
Discharge Port Type | O-Ring / Gasket |
Distance From Clutch To Mounting Flange | 0.640625 |
Mounting Hardware | Not Included |
Mounting Type | Tangent Mount |
New or Reman | New |
O-Ring A Number/Desc | [24068] / Gasket |
O-Ring A Quantity | 1 |
O-Ring B Number/Desc | [24069] / Gasket |
O-Ring B Quantity | 1 |
Printed Foot Note | May Require use of OE Manifold |
Pulley Belt Type | Serpentine |
Pulley Diameter MM | 119.380 |
Pulley Groove Quantity | 6 |
Pulley Lip Diameter | 4.703125 |
Pulley Outside Diameter | 4.703125 |
Pulley Ridge Diameter | 4.703125 |
Refrigerant Type | R134a |
Suction Port Type | O-Ring / Gasket |
Terminal Type | 2 Lead Wires w/ Connector |
UPC | 096361625006 |
w/ Diode | No |
Year Make Model | Trim | Engine |
---|---|---|
2007-2008 Dodge Sprinter 2500 | All Trims | 6 Cyl 3.0L |
2009 Dodge Sprinter 2500 | All Trims | All Engines |
2007-2008 Dodge Sprinter 3500 | All Trims | 6 Cyl 3.0L |
2009 Dodge Sprinter 3500 | All Trims | All Engines |
2010 Mercedes-Benz SLK300 | All Trims | All Engines |
2013-2018 Mercedes-Benz Sprinter | All Trims | All Engines |
2013-2015 Mercedes-Benz Sprinter 2500 | All Trims | All Engines |
2016-2017 Mercedes-Benz Sprinter 2500 | All Trims | 4 Cyl 2.1L |
2016-2017 Mercedes-Benz Sprinter 2500 | All Trims | 6 Cyl 3.0L |
2018 Mercedes-Benz Sprinter 2500 | All Trims | All Engines |
