Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 46124 |
Part Description | Electronic Engine Cooling Fan Clutch |
Bolt Hole Quantity | 4 |
Bolt Thread | M6 x 1.0 STUD |
Clutch Maximum Diameter | 9.39 |
Clutch Type | D - Severe Duty & Truck Fan Drive |
Color | Raw Aluminum in Color |
Distance From Clutch To Mounting Flange | 3.8 |
Fan Bolt Circle IN | 8.66 |
Material | Aluminum |
Meets / Exceeds OEM | Yes |
Mount Dia. IN | 2.09 (53mm) HEX |
Mounting Hardware | Not Included |
Mounting Hole Quantity | 4 |
Mounting Type | HEX |
New or Reman | New |
Overall Height IN | 5.33 |
Performance Rated | Yes |
Pilot Depth IN | 1.83 |
Rotation | REV |
SDS Required | No (135233618) |
Style | Severe Duty |
UPC | 096361000889 |
Use Type | Electro-Viscous |
Year Make Model | Trim | Engine |
---|---|---|
2015-2016 Chevrolet Silverado 2500 HD | All Trims | 8 Cyl 6.6L |
2015-2016 Chevrolet Silverado 3500 HD | All Trims | 8 Cyl 6.6L |
2015-2016 GMC Sierra 2500 HD | All Trims | 8 Cyl 6.6L |
2015-2016 GMC Sierra 3500 HD | All Trims | 8 Cyl 6.6L |
