Vehicle Specific
Check if it fits by entering your vehicle infoBrand | Four Seasons |
Part Number | 46121 |
Part Description | Electronic Engine Cooling Fan Clutch |
Bolt Hole Quantity | 4 |
Bolt Thread | M6x1.000 |
Clutch Maximum Diameter | 8.38 |
Clutch Type | Electronic |
Color | Raw Aluminum in Color |
Distance From Clutch To Mounting Flange | 3.12 |
Fan Bolt Circle IN | 7.72 |
Material | Aluminum |
Meets / Exceeds OEM | Yes |
Mount Dia. IN | 3.31 |
Mounting Hardware | Not Included |
Mounting Hole Quantity | 4 |
Mounting Type | Flange |
New or Reman | New |
Overall Height IN | 4.34 |
Performance Rated | Yes |
Pilot Depth IN | 0.59 |
Pilot Dia. IN | 1.5 |
Rotation | REV |
SDS Required | No (135233618) |
Style | Severe Duty |
UPC | 096361031029 |
Use Type | Electro-Viscous |
Year Make Model | Trim | Engine |
---|---|---|
2011-2013 Infiniti QX56 | All Trims | All Engines |
2014-2018 Infiniti QX80 | All Trims | All Engines |
2017-2018 Nissan Armada | All Trims | All Engines |
2017-2018 Nissan NV2500 | All Trims | 8 Cyl 5.6L |
2017-2018 Nissan NV3500 | All Trims | 8 Cyl 5.6L |
2017-2018 Nissan Titan | All Trims | All Engines |
2016-2018 Nissan Titan XD | All Trims | 8 Cyl 5.6L |
